Panasonic FP0 - Page 269

14-27
Address
FP0 T32
FP0 C10,
C14, C16,
C32, SL1
Name Descriptions
DT90104 DT9104
DT90105 DT9105
High-speed counter
elapsed value area for
ch2
The elapsed value (24-bit data) for the high-
speed counter is stored here. Each time the ED
instruction is executed, the elapsed value for the
high-speed counter is automatically transferred
to the special registers DT9104 and
DT9015/DT90104 and DT90105.
The value can be written by executing a DMV
(F1) instruciton.
DT90106 DT9106
DT90107 DT9107
High-speed counter
target value area for
ch2
The target value (24-bit data) of the high-speed
counter specified by the high-speed counter
instruction is stored here.
Target values have been preset for the various
instructions, to be used when the high-speed
counter related instruction F166 to F170 is
executed. These preset values can only be read,
and cannot be written.
DT90108 DT9108
DT90109 DT9109
High-speed counter
elapsed value area for
ch3
The elapsed value (24-bit data) of the high-
speed counter is stored here. Each time the ED
instruction is executed, the elapsed value for the
high-speed counter is automatically transferred
to the special registers DT9108 and
DT9109/DT90108 and DT90109.
The value can be written by executing a DMV
(F1) instruction.
DT90110 DT9110
DT90111 DT9111
High-speed counter
target value area for
ch3
The target value (24-bit data) of the high-speed
counter specified by the high-speed counter
instruction is stored here.
Target values have been preset for the various
instructions, to be used when the high-speed
counter related instruction F166 to F170 is
executed. These preset values can only be read,
and cannot be written.
