2.4 Pin Layouts
2.4 Pin Layouts
2.4.1 C10RS/C10CRS/C10RM/C10CRM
Input
Output
COM
X0
X1
(NC)
(NC)
X2
X3
X4
X5
COM
Y0
Y1
COM
Y3
(NC)
(NC)
COM
Y2
Power supply
X0−5
Y0−3
C10RS/C10CRS C10RM/C10CRM
X0
X5
COM
Y0
Y3
COM
Load
Load
(* Note)
Y0−3 Y0−3
Power supply
Load
Load
X0−5X0−5
2.4.2 C14RS/C14CRS/C14RM/C14CRM
C14RS/C14CRS
C14RM/C14CRM
X0
X7
COM
Y0
Y5
COM
COM
X0
X1
X6
X7
X2
X3
X4
X5
COM
Y0
Y1
COM
Y5
Y2
Y3
COM
Y4
Input
Output
X0−7
Y0−5
(* Note)
Power supply
Load
Load
Load
Load
Load
Load
Power supply
Power supply
X0−7X0−7
Y0−5
Note
Either positive or negative polarity is possible for the input
voltage supply.
