Parker 690+ series - MOTOR DATA

Programming Your Application 1-55
690+ Series Frequency Inverter
MOTOR DATA
Designed for all Motor Control
Modes.
In this function block you enter the
details of the motor under control and
any available motor nameplate
information.
The Autotune feature will determine the
MAG CURRENT, STATOR RES,
LEAKAGE INDUC, MUTUAL INDUC
and ROTOR TIME CONST motor
model parameter.
The OVERLOAD parameter
determines the allowed level of motor
overload. This can be especially useful
when operating with motors smaller
than the inverter rating.
Note: Do not attempt to control motors whose rated current is less than 25% of the
drive rated current. Poor motor control or Autotune problems may occur if you
do.
Motor Data
** VOLTS / HZ
–
[1157] CONTROL MODE
–
** 5.50 kW
–
[1158] POWER
–
** 50.0 Hz
–
[1159] BASE FREQUENCY
–
** 400.0 V
–
[1160] MOTOR VOLTAGE
–
** 11.30 A
–
[ 64] MOTOR CURRENT
–
** 3.39 A
–
[ 65] MAG CURRENT
–
** 1445.0 rpm
–
[ 83] NAMEPLATE RPM
–
** STAR
–
[124] MOTOR CONNECTION
–
** 4 POLE
–
[ 84] MOTOR POLES
–
** 0.90
–
[242] POWER FACTOR
–
** 2.0
–
[1164] OVERLOAD
–
** 1.3625 Ohm
–
[119] STATOR RES
–
** 43.37 mH
–
[120] LEAKAGE INDUC
–
** 173.48 mH
–
[121] MUTUAL INDUC
–
276.04 ms
–
[1163] ROTOR TIME CONST
–
MMI Menu Map
1
SETUP
2
MOTOR CONTROL
3
MOTOR DATA
CONTROL MODE
POWER
BASE FREQUENCY
MOTOR VOLTAGE
MOTOR CURRENT
MAG CURRENT
NAMEPLATE RPM
MOTOR
CONNECTION
MOTOR POLES
POWER FACTOR
OVERLOAD
STATOR RES
LEAKAGE INDUC
MUTUAL INDUC
ROTOR TIME CONST
Parameter Descriptions
CONTROL MODE
Range: Enumerated - see below
Determines the main method of motor control used by the inverter.
Enumerated Value : Control Mode
0 : VOLTS / HZ
1 : SENSORLESS VEC
2 : CLOSED-LOOP VEC
3 : 4-Q REGEN
POWER
Range: 0.00 to 3000.00kW
This parameter contains the motor nameplate power.
BASE FREQUENCY
Range: 7.5 to 1000.0Hz
This parameter contains the motor nameplate base frequency. Refer to
FLUXING, page 1-38.
MOTOR VOLTAGE
Range: 0.0 t
o 575.0V
This parameter contains the motor nameplate voltage at base frequency. Refer to VOLTAGE
C
ONTROL, page 1-134.
MOTOR CURRENT
Range: 0.00 to 5000.00A
This parameter contains the motor nameplate full-load line current.
MAG CURRENT
Range: 0.00 to 5000.00A
This parameter contains the motor model no-load line current as determined by the auto-tune.
