Programming Your Application 1-113
690+ Series Frequency Inverter
SYSTEM OPTION
This function block is used to select the
System Board option required.
If a System Board is fitted, the block reports
the type, version and working status of the
option.
If a System Board is present when defaults are
loaded, the REQUIRED TYPE parameter is automatically set.
MMI Menu Map
1
SETUP
2
INPUTS & OUTPUTS
3
SYSTEM OPTION
REQUIRED TYPE
FAULT
ACTUAL TYPE
VERSION
FEATURES
System Option
FAULT [1293]
–
NONE
ACTUAL TYPE [1294]
–
NONE
VERSION [1295]
–
0000
FEATURES [1498]
–
0000
NONE
[1292] REQUIRED TYPE
–
Parameter Descriptions
REQUIRED TYPE
Range: Enumerated - see below
Selects the type of System Board option required to be fitted for the application to operate
correctly.
Enumerated Value : Option Type
0 : NONE
1 : DUAL ENCODER
2 : TYPE 2
3 : TYPE 3
4 : TYPE 4
5 : TYPE 5
6 : TYPE 6
7 : TYPE 7
8 : TYPE 8
FAULT
Range: Enumerated - see below
The fault state of the System Board Option.
Enumerated Value : Fault State
0 : NONE
1 : PARAMETER VALUE
2 : TYPE MISMATCH
3 : SELFTEST
4 : HARDWARE
5 : MISSING
ACTUAL TYPE
Range: 0x0000 to 0xFFFF
The type of System Board option fitted.
Enumerated Value : Option Type
0 : NONE
1 : DUAL ENCODER
2 : TYPE 2
3 : TYPE 3
4 : TYPE 4
5 : TYPE 5
6 : TYPE 6
7 : TYPE 7
8 : TYPE 8
VERSION
Range: 0x0000 to 0xFFFF
The version of the System Board Option. If no option is fitted, or it is faulty, then the version is
reset to zero.
FEATURES
Range: 0x0000 to 0xFFFF
A diagnostic bit field parameter indicating the features supported by the System Board.
Enumerated Value : Features
Bit 0 : 12 BIT ANALOG IN (FALSE / TRUE)
Bit 1 : DIGITAL IO (FALSE / TRUE)
Bit 2 : ENCODER INPUTS (FALSE / TRUE)
Bit 3 : MARK INPUTS (FALSE / TRUE)
To Next Page
