Programming Your Application 1-15
690+ Series Frequency Inverter
AUTO RESTART
Auto Restart (or Auto Reset) provides the
facility to automatically reset a choice of trip
events and restart the drive with a
programmed number of attempts, after
which, a manual or remote trip reset is
required if the drive is not successfully
restarted. The number of attempted restarts
are recorded. This count is cleared after a
trip-free period of operation
(5 minutes or 4 x ATTEMPT DELAY 1,
whichever is the longer), or after a
successful manual or remote trip reset, or by
removing the Run signal, or by setting the
ENABLE input to this block FALSE.
Auto Restart
PENDING [608]
FALSE
RESTARTING [616]
FALSE
ATTEMPTS LEFT [614]
5
TIME LEFT [615]
0.0 s
FALSE
[611] ENABLE
5
[612] ATTEMPTS
10.0 s
[610] INITIAL DELAY 1
10.0 s
[613] ATTEMPT DELAY 1
0000
[609] TRIGGERS 1
0000
[744] TRIGGERS 1+
0.1 s
[678] INITIAL DELAY 2
0.1 s
[679] ATTEMPT DELAY 2
0000
[677] TRIGGERS 2
0000
[745] TRIGGERS 2+
MMI Menu Map
1
SETUP
2
SEQ & REF
3
A
UTO RESTART
ENABLE
ATTEMPTS
INITIAL DELAY 1
ATTEMPT DELAY 1
TRIGGERS 1
TRIGGERS 1+
INITIAL DELAY 2
ATTEMPT DELAY 2
TRIGGERS 2
TRIGGERS 2+
PENDING
RESTARTING
ATTEMPTS LEFT
TIME LEFT
Parameter Descriptions
ENABLE
Range: FALSE / TRUE
Enables operation of the auto restart feature.
ATTEMPTS
Range: 1 to 10
Determines the number of restarts that will be permitted before requiring an external fault
reset.
INITIAL DELAY 1
Range: 0.0 to 600.0 s
Determines the delay for the first restart attempt when the trip is included in TRIGGERS 1 .
The delay is measured from all error conditions clearing.
ATTEMPT DELAY 1
Range: 0.0 to 600.0 s
Determines the delay between restart attempts for a trip included in TRIGGERS 1 . The delay
is measured from all error conditions clearing.
TRIGGERS 1 and TRIGGERS+ 1
Range: 0x0000 to 0xFFFF
Allows Auto Restart to be enabled for a selection of trip conditions.
Refer to TRIPS STATUS, page 1-124, for an explanation of the four-digit codes.
INITIAL DELAY 2
Range: 0.0 to 600.0 s
Determines the delay for the first restart attempt when the trip is included in TRIGGERS 2
The delay is measured from all error conditions clearing.
ATTEMPT DELAY 2
Range: 0.0 to 600.0 s
Determines the delay between restart attempts for a trip included in TRIGGERS 2 . The delay
is measured from all error conditions clearing.
TRIGGERS 2 and TRIGGERS+ 2
Range:0x0000 to 0xFFFF
Allows Auto Restart to be enabled for a selection of trip conditions.
If a trip is included in both TRIGGERS 1 and TRIGGERS 2, then the times associated with
TRIGGERS 1 will take priority.
Refer to the Installation Product Manual, Chapter 6: “Hexadecimal Representation of Trips”
for an explanation of the four-digit codes.
