690+ Series Frequency Inverter
REFERENCE JOG
This block holds all the parameters that
concern the Jog functionality on the
Inverter.
Functional Description
The REFERENCE JOG function block is used to configure the action of the Inverter when used
in jog mode. The various operating modes are described in more detail in the Installation
Product Manual, Chapter 4: “Operating the Inverter” - The Start/Stop Mode Explained.
Reference Jog
10.00 %
–
[246] SETPOINT
–
1.0 s
–
[261] ACCEL TIME
–
1.0 s
–
[262] DECEL TIME
–
MMI Menu Map
1
SETUP
2
SEQ & REF
3
REFERENCE JOG
SETPOINT
ACCEL TIME
DECEL TIME
Parameter Descriptions
SETPOINT
Range: -100.00 to 100.00 %
The setpoint is the target reference that the Inverter will ramp to.
ACCEL TIME
Range: 0.0 to 3000.0 s
The time that the Inverter will take to ramp the jog setpoint from 0.00% to 100.00%.
DECEL TIME
Range: 0.0 to 3000.0 s
The time that the Inverter will take to ramp the jog setpoint from 100.00% to 0.00%.
