PHASE OFFSET
The Offset function block adds an
offset to the error calculator. This is
unramped.
OffsetFineOffsetErrortPhaseOutpu ++=
Phase Offset
–
ACTIVE [1512]
–
FALSE
0.0
–
[1510] OFFSET
–
0.0000
–
[1511] OFFSET FINE
–
MMI Menu Map
1
SETUP
2
SYSTEM BOARD
3
PHASE OFFSET
OFFSET
OFFSET FINE
ACTIVE
Parameter Descriptions
OFFSET
Range: -3000.0 to 3000.0
A course offset added to the phase error, allowing an absolute phase correction to be applied.
The Offset is added to the Phase at a maximum rate of +/-32768 counts.
OFFSET FINE
Range: -1.0000 to 1.0000
Additional correction added to OFFSET to allow fine control of position.
ACTIVE
Range: FALSE / TRUE
TRUE while offset count is being added.
