Parker 690+ series User Manual

Programming Your Application 1-23
690+ Series Frequency Inverter
DEMULTIPLEXER
The demultiplexer function block splits the input word into 16 individual bits.
This may be used to extract the individual trip bits from the ACTIVE TRIPS parameter, for
example.
MMI Menu Map
1
SETUP
2
MISCELLANEOUS
3
DEMULTIPLEXER
4
DEMULTIPLEXER 1
4
DEMULTIPLEXER 2
INPUT
OUTPUT 0
OUTPUT 1
OUTPUT 2
OUTPUT 3
OUTPUT 4
OUTPUT 5
OUTPUT 6
OUTPUT 7
OUTPUT 8
OUTPUT 9
OUTPUT 10
OUTPUT 11
OUTPUT 12
OUTPUT 13
OUTPUT 14
OUTPUT 15
Demultiplexer 1
OUTPUT 0 [657]
–
FALSE
OUTPUT 1 [658]
–
FALSE
OUTPUT 2 [659]
–
FALSE
OUTPUT 3 [660]
–
FALSE
OUTPUT 4 [661]
–
FALSE
OUTPUT 5 [662]
–
FALSE
OUTPUT 6 [663]
–
FALSE
OUTPUT 7 [664]
–
FALSE
OUTPUT 8 [665]
–
FALSE
OUTPUT 9 [666]
–
FALSE
OUTPUT 10 [667]
–
FALSE
OUTPUT 11 [668]
–
FALSE
OUTPUT 12 [669]
–
FALSE
OUTPUT 13 [670]
–
FALSE
OUTPUT 14 [671]
–
FALSE
OUTPUT 15 [672]
–
FALSE
0000
–
[599] INPUT
–
Demultiplexer 2
OUTPUT 0 [875]
–
FALSE
OUTPUT 1 [1000]
–
FALSE
OUTPUT 2 [1001]
–
FALSE
OUTPUT 3 [1002]
–
FALSE
OUTPUT 4 [1003]
–
FALSE
OUTPUT 5 [1004]
–
FALSE
OUTPUT 6 [1005]
–
FALSE
OUTPUT 7 [1006]
–
FALSE
OUTPUT 8 [1007]
–
FALSE
OUTPUT 9 [1008]
–
FALSE
OUTPUT 10 [1009]
–
FALSE
OUTPUT 11 [1010]
–
FALSE
OUTPUT 12 [1011]
–
FALSE
OUTPUT 13 [1012]
–
FALSE
OUTPUT 14 [1013]
–
FALSE
OUTPUT 15 [1014]
–
FALSE
0000
–
[874] INPUT
–
Parameter Descriptions
INPUT
Range: 0x0000 to 0xFFFF
The input to be split into its component bits.
OUTPUT 0 TO OUTPUT 15
Range: FALSE / TRUE
Each output returns the corresponding bit of the 16 bit input word.
