1-114 Programming Your Application
690+ Series Frequency Inverter
SYSTEM PORT (P3)
The unisolated RS232 programming port(s)
allows for connection to the Operator
Station, or to a personal computer for drive
configuration and storage of parameters.
The parameters below are used to identify
the Inverter to the controlling software.
The port uses the Parker SSD Drives standard EI BISYNCH ASCII protocol.
Functional Description
The unit will always respond to GID = 0 and UID = 0, as this is the “broadcast” address used by
the Operator Station.
Note: The Technology Option uses a different port and address. It does not respond to the
“broadcast” address.
System Port (P3)
EI ASCII [117] MODE
0 [102] GROUP ID (GID)
0
[103] UNIT ID (UID)
MMI Menu Map
1
SETUP
2
COMMUNICATIONS
3
SYSTEM PORT (P3)
MODE
GROUP ID (GID)
UNIT ID (UID)
Parameter Descriptions
MODE
Range: 0 to 1
Selects the P3 port to operate with the Operator Station (EI ASCII), or a Parker SSD Drives'
5703 Setpoint Repeater.
This parameter must be set to 5703 for the 5703 INPUT and 5703 OUTPUT function blocks to
operate. Refer to pages 1-
7 and 1-8.
Note: The P3 port always operates in the EI ASCII mode when in Configuration Mode.
Enumerat
ed Value : Mode
0 : EI ASCII
1 : 5703
GROUP ID (GID)
Range: 0 to 9
The Parker SSD Drives protocol group identity address.
UNIT ID (UID)
Range: 0 to 15
The Parker SSD Drives protocol unit identity address
