Parker 690+ series - OPERATOR MENU

Programming Your Application 1-59

690+ Series Frequency Inverter

OPERATOR MENU

These function blocks are used to configure the Operator menu. This feature provides quick

access to frequently used parameters. Any parameter may be “promoted” to the Operator menu,

and the parameter is then automatically saved on power-down.

In addition, parameters displayed in the Operator menu may be given a different name, and may

be rescaled for display using the DISPLAY SCALE function blocks.

Operator Menu 3

NULL

–

[626] PARAMETER

–

[1045] NAME

–

NONE

–

[1046] SCALING

–

FALSE

–

[1047] READ ONLY

–

FALSE

–

[1048] IGNORE PASSWORD

–

Operator Menu 5

NULL

–

[628] PARAMETER

–

[1053] NAME

–

NONE

–

[1054] SCALING

–

FALSE

–

[1055] READ ONLY

–

FALSE

–

[1056] IGNORE PASSWORD

–

MMI Menu Map

1

SETUP

2

MENUS

3

OPERATOR MENU

4

OPERATOR MENU 1

4

OPERATOR MENU 2

4

OPERATOR MENU 3

4

OPERATOR MENU 4

4

OPERATOR MENU 5

4

OPERATOR MENU 6

4

OPERATOR MENU 7

4

OPERATOR MENU 8

4

OPERATOR MENU 9

4

OPERATOR MENU 10

4

OPERATOR MENU 11

4

OPERATOR MENU 12

4

OPERATOR MENU 13

4

OPERATOR MENU 14

4

OPERATOR MENU 15

4

OPERATOR MENU 16

PARAMETER

NAME

SCALING

READ ONLY

IGNORE PASSWORD

Operator Menu 4

NULL

–

[627] PARAMETER

–

[1049] NAME

–

NONE

–

[1050] SCALING

–

FALSE

–

[1051] READ ONLY

–

FALSE

–

[1052] IGNORE PASSWORD

–

Operator Menu 2

NULL

–

[371] PARAMETER

–

[378] NAME

–

NONE

–

[1042] SCALING

–

FALSE

–

[1043] READ ONLY

–

FALSE

–

[1044] IGNORE PASSWORD

–

Operator Menu 6

NULL

–

[629] PARAMETER

–

[1057] NAME

–

NONE

–

[1058] SCALING

–

FALSE

–

[1059] READ ONLY

–

FALSE

–

[1060] IGNORE PASSWORD

–

Operator Menu 8

NULL

–

[631] PARAMETER

–

[1065] NAME

–

NONE

–

[1066] SCALING

–

FALSE

–

[1067] READ ONLY

–

FALSE

–

[1068] IGNORE PASSWORD

–

Operator Menu 10

NULL

–

[633] PARAMETER

–

[1073] NAME

–

NONE

–

[1074] SCALING

–

FALSE

–

[1075] READ ONLY

–

FALSE

–

[1076] IGNORE PASSWORD

–

Operator Menu 1

NULL

–

[ 74] PARAMETER

–

[324] NAME

–

NONE

–

[1039] SCALING

–

FALSE

–

[1040] READ ONLY

–

FALSE

–

[1041] IGNORE PASSWORD

–

Operator Menu 7

NULL

–

[630] PARAMETER

–

[1061] NAME

–

NONE

–

[1062] SCALING

–

FALSE

–

[1063] READ ONLY

–

FALSE

–

[1064] IGNORE PASSWORD

–

Operator Menu 9

NULL

–

[632] PARAMETER

–

[1069] NAME

–

NONE

–

[1070] SCALING

–

FALSE

–

[1071] READ ONLY

–

FALSE

–

[1072] IGNORE PASSWORD

–

Operator Menu 11

NULL

–

[634] PARAMETER

–

[1077] NAME

–

NONE

–

[1078] SCALING

–

FALSE

–

[1079] READ ONLY

–

FALSE

–

[1080] IGNORE PASSWORD

–

Operator Menu 12

NULL

–

[635] PARAMETER

–

[1081] NAME

–

NONE

–

[1082] SCALING

–

FALSE

–

[1083] READ ONLY

–

FALSE

–

[1084] IGNORE PASSWORD

–

Operator Menu 15

NULL

–

[638] PARAMETER

–

[1093] NAME

–

NONE

–

[1094] SCALING

–

FALSE

–

[1095] READ ONLY

–

FALSE

–

[1096] IGNORE PASSWORD

–

Operator Menu 13

NULL

–

[636] PARAMETER

–

[1085] NAME

–

NONE

–

[1086] SCALING

–

FALSE

–

[1087] READ ONLY

–

FALSE

–

[1088] IGNORE PASSWORD

–

Operator Menu 14

NULL

–

[637] PARAMETER

–

[1089] NAME

–

NONE

–

[1090] SCALING

–

FALSE

–

[1091] READ ONLY

–

FALSE

–

[1092] IGNORE PASSWORD

–

Operator Menu 16

NULL

–

[639] PARAMETER

–

[1097] NAME

–

NONE

–

[1098] SCALING

–

FALSE

–

[1099] READ ONLY

–

FALSE

–

[1100] IGNORE PASSWORD

–
