Parameter Specification 2-1
690+ Series Frequency Inverter
2PARAMETER SPECIFICATION
The headings for the Tag No. table are described below.
Tag A numeric identification of the parameter. It is used to identify the source and
destinations of internal links.
Name The parameter name as it appears on the MMI.
Block The menu page and function block under which the parameter is stored.
Type REAL
INT
BOOL
ENUM
STRING
TAG
D_TAG
S_TAG
WORD
Floating point value
Integer value
A Boolean (bit) representing FALSE or TRUE
An enumerated value representing a selection
An ASCII string
A value representing a choice of TAG
A value representing a choice of Destination tag as an internal
link
A value representing a choice of Source tag as an internal link
16 Bit hexadecimal number
Range This varies with parameter type:
REAL,
INT
BOOL
ENUM
STRING
TAG
D_TAG
S_TAG
WORD
The upper and lower limits of the parameter
0 = FALSE, 1 = TRUE
A list of possible selections for that parameter
Specified number of characters
The tag number of any parameter
The tag number of an input parameter
The tag number of an input or output parameter.
0000 to FFFF (hexadecimal), numbered lists show Bit numbers
Note: Decimal Places: “—” signifies an indeterminable number of units. An
“x” signifies a decimal place, e.g. —.xx % could represent
100.00 %.
ID Serial Communications Mnemonic:
Refer to Chapter 3: “Serial Communications”
Notes
You can record your application’s settings here.
Output parameters are not saved in non-volatile memory unless indicated.
1. This input parameter is not saved in non-volatile memory.
2. This parameter is automatically saved in non-volatile memory.
3. This parameter forms part of the motor configuration.
4. This parameter is not adjustable from the operator station.
5. This parameter cannot be the destination of a link.
6. This parameter cannot be the source of a link.
7. This input parameter can only be written to when the Inverter is stopped.
8. This input parameter can only be written to when the Inverter is in
configuration mode.
9. This input parameter is not writable from serial comms.
10. This parameter uses special scaling rules when accessed using certain
Comms options of the 6053 Technology Box. Refer to page 2-
41.
