1-34 Programming Your Application
690+ Series Frequency Inverter
ENERGY METER
This block measures the electrical energy
used by the load.
Energy Meter
–
POWER [1604]
–
0.00 kW
–
POWER [1605]
–
0.00 HP
–
REACTIVE POWER [1606]
–
0.00 kVAr
–
ENERGY USED [1607]
–
0.0 kWh
FALSE
–
[1603] RESET
–
MMI Menu Map
1
SETUP
2
MOTOR CONTROL
3
ENERGY METER
RESET
POWER
POWER
REACTIVE POWER
ENERGY USED
Parameter Descriptions
RESET
Range: FALSE / TRUE
When RESET is set to TRUE, the ENERGY USED parameter is reset to zero automatically
when the maximum value is reached.
When RESET is set to FALSE, the ENERGY USED parameter is held at the maximum value
when the maximum value has been reached
Changing this from FALSE to TRUE at anytime will cause the ENERGY USED parameter to
be reset to zero.
POWER
Range: -32768.00 to 32767.00 kW
This diagnostic shows the power being delivered to the load in kilowatts.
POWER
Range: -32768.00 to 32767.00 HP
This diagnostic shows the power being delivered to the load in horsepower.
REACTIVE POWER
Range: -32768.00 to 32767.00
kVAr
This diagnostic shows the reactive power being delivered to the load in kilovolt-amperes
reactive.
ENERGY USED
Range: 0.00 to 32767.00 kWh
This diagnostic shows the total energy consumed by the load in kilowatt hours.
