690+ Series Frequency Inverter

PHASE CONTROL

This is the principal phase function block

and controls the error generation as well

as the feed-forward calculation.

MMI Menu Map

SETUP

SYSTEM BOARD

PHASE CONTROL

RESET (TOTAL)

POSITION ENABLE

SPEED INPUT

INVERT SPEED OP

GEARING A

GEARING B

FDFWD SCALE

OUTPUT SCALE

INVERT OUTPUT

OUTPUT

SPEED OUTPUT

POS FEED FWD

SLAVE POS (INT)

MASTER POS (INT)

MASTER POSITION

MSTR POS+OFFSET

SLAVE POSITION

POS ERROR INT

POSITION ERROR

Parameter Descriptions

RESET (TOTAL)

Range: FALSE / TRUE

Total Reset, disables both the SPEED OUPUT and PHASE LOOP, see POSITION ENABLE.

POSITION ENABLE

Range: FALSE / TRUE

The position enable input. Enables the operation of the accumulator. If set FALSE, then the

accumulator is set to zero and any phase information is reset. See also RESET (TOTAL).

SPEED INPUT

Range: -300.00 to 300.00

Input to the speed feed-forward calculator, to obtain good phase locking it is important that this

input is used. The speed input will usually be the master line speed, this input should be set such

that the slave will follow the master even with the phase loop disabled.

INVERT SPEED OP

Range: FALSE / TRUE

Invert the speed output.

GEARING A

Range: -30000 to 30000

Gearing allows the slave to run at a ratio of the master speed / position.

⎟

⎠

⎞

⎜

⎝

⎛

×=

GearingB

GearingA

erPositionActualMasttionMasterPosi

⎟

⎠

⎞

⎜

⎝

⎛

×=

GearingB

GearingA

SpeedInputtSpeedOutpu

GEARING B

Range: -30000 to 30000

See Gearing A

FDFWD SCALE

Range: -300.00 to 300.00

Scale position feed-forward. Scaled with PHASE CONFIG::MAX SPEED. This feed forward

works only for position setpoint changes and is designed to reduce the following error of the

system by predicting the torque required to accelerate the motor.

OUTPUT SCALE

Range: 0.00 to 300.00

Scales the position output.

INVERT OUTPUT

Range: FALSE / TRUE

Inverts the position output.

Phase Control

–

OUTPUT [1488]

–

0.00

–

SPEED OUTPUT [1489]

–

0.00

–

POS FEED FWD [1490]

–

0.00

–

SLAVE POS (INT) [1841]

–

MASTER POS (INT) [1491]

–

MASTER POSITION [1492]

–

0.00

–

MSTR POS+OFFSET [1842]

–

SLAVE POSITION [1493]

–

0.00

–

POS ERROR INT [1494]

–

POSITION ERROR [1495]

–

0.00

FALSE

–

[1479] RESET (TOTAL)

–

FALSE

–

[1480] POSITION ENABLE

–

0.00

–

[1481] SPEED INPUT

–

FALSE

–

[1482] INVERT SPEED OP

–

[1483] GEARING A

–

[1484] GEARING B

–

1.00

–

[1485] FDFWD SCALE

–

1.00

–

[1486] OUTPUT SCALE

–

FALSE

–

[1487] INVERT OUTPUT

–
