SKIP FREQUENCIES
This function block may be used to prevent
the Inverter operating at frequencies that
cause mechanical resonance in the load.
Skip Frequencies
OUTPUT [346]
–
0.00 %
OUTPUT HZ [363]
–
0.0 Hz
INPUT HZ [362]
–
0.0 Hz
0.00 % – [340] INPUT
–
0.0 Hz
–
[341] BAND 1
–
0.0 Hz
–
[342] FREQUENCY 1
–
0.0 Hz
–
[680] BAND 2
–
0.0 Hz
–
[343] FREQUENCY 2
–
0.0 Hz
–
[681] BAND 3
–
0.0 Hz
–
[344] FREQUENCY 3
–
0.0 Hz
–
[682] BAND 4
–
0.0 Hz
–
[345] FREQUENCY 4
–
MMI Menu Map
1
SETUP
2
SETPOINT FUNCS
3
SKIP FREQUENCIES
INPUT
BAND 1
FREQUENCY 1
BAND 2
FREQUENCY 2
BAND 3
FREQUENCY 3
BAND 4
FREQUENCY 4
OUTPUT
OUTPUT Hz
INPUT Hz
Parameter Descriptions
INPUT
Range: -300.00 to 300.00 %
The value of the block input in %.
BAND 1
Range: 0.0 to 480.0 Hz
The width of each skip band in Hz.
FREQUENCY 1
Range: 0.0 to 480.0 Hz
This parameter contains the centre frequency of each skip band in Hz.
BAND 2
Range: 0.0 to 480.0 Hz
The width of each skip band in Hz.
FREQUENCY 2
Range: 0.0 to 480.0 Hz
This parameter contains the centre frequency of each skip band in Hz.
BAND 3
Range: 0.0 to 480.0 Hz
The width of each skip band in Hz.
FREQUENCY 3
Range: 0.0 to 480.0 Hz
This parameter contains the centre frequency of each skip band in Hz.
BAND 4
Range: 0.0 to 480.0 Hz
The width of each skip band in Hz.
FREQUENCY 4
Range: 0.0 to 480.0 Hz
This parameter contains the centre frequency of each skip band in Hz.
OUTPUT
Range: —.xx %
Diagnostic on the output of the function block in %
OUTPUT HZ
Range: —.x Hz
Diagnostic on the output of the function block in Hz
INPUT HZ
Range: —.x Hz
Diagnostic on the input of the function block in Hz
