Programming Your Application 1-9
690+ Series Frequency Inverter
ACCESS CONTROL
This function block contains options
associated with operator station password
protection, view levels, setpoint display and
initial Operator Menu selection.
Access Control
BASIC
[876] VIEW LEVEL
0000
[ 8] PASSWORD
[339] CONFIG NAME
NONE
[1037] SETPOINT SCALE
FALSE
[1038] NO SETPOINT PWRD
0
[ 93] STARTUP SCREEN
Parameter Descriptions
VIEW LEVEL
Range: FALSE / TRUE
The menu to be displayed by the Operator Station. Refer to the Installation Product Manual,
Chapter 5: “The Operator Station” - Menu Viewing Levels.
Enumerated Value : View Level
0 : OPERATOR
1 : BASIC
2 : ADVANCED
PASSWORD
Range: 0x0000 to 0xFFFF
Setting a non-zero value enables the password feature.
CONFIG NAME
Range: max length is 16 chars
When not blank, the string is displayed as the top line of the Welcome screen.
SETPOINT SCALE
Range: See below
A scaling factor applied to the speed setpoint and feedback displays. Selects a DISPLAY
SCALE function block to be applied.
Enumerated Value : DISPLAY SCALE function block
0 : NONE
1 : DISPLAY SCALE 1
2 : DISPLAY SCALE 2
3 : DISPLAY SCALE 3
4 : DISPLAY SCALE 4
NO SETPOINT PWRD
Range: FALSE / TRUE
When TRUE, the local setpoint is not password protected, regardless of the PASSWORD
value. When FALSE, the local setpoint is password protected just like all other parameters.
STARUP SCREEN
Range: See below
Selects which of the Operator Menu parameters will be displayed after the Welcome screen.
Enumerated Value : Startup Screen
0 : selects REMOTE SETPOINT or LOCAL SETPOINT
1 : selects parameter defined by OPERATOR MENU 1
2 : selects parameter defined by OPERATOR MENU 2
: etc.
16 : selects parameter defined by OPERATOR MENU 16
MMI Menu Map
1
SETUP
2
MENUS
3
A
CCESS CONTROL
VIEW LEVEL
PASSWORD
CONFIG NAME
SETPOINT SCALE
NO SETPOINT PWRD
STARTUP SCREEN
