Application Macros 5-23

690+ Series Frequency Inverter

Autotune

– ACTIVE [604]– FALSE

FALSE – [603] ENABLE –

Comms Control

– COMMS SEQ [295]– FALSE

– COMMS REF [270]– FALSE

– COMMS STATUS[272]– 0

– COMMS COMMAND[273]– 0

FALSE – [300] REMOTE COMMS SEL–

TERMINALS/COMMS– [307] REMOTE SEQ MODES–

TERMINALS/COMMS– [308] REMOTE REF MODES–

0.0 s – [309] COMMS TIMEOUT –

Local Control

REMOTE SEQ[297] –TRUE

REMOTE REF[257] –TRUE

LOCAL/REMOTE– [298] SEQ MODES –

LOCAL/REMOTE– [265] REF MODES –

REMOTE– [299] POWER UP MODE–

FALSE– [281] SEQ DIRECTION –

Pattern Gen

– DRIVE FREQUENCY[591]– 0.00 Hz

TRUE – [ 98] RANDOM PATTERN–

3 kHz – [ 99] FREQ SELECT –

** 2.0 s – [100] DEFLUX DELAY –

Slew Rate Limit

TRUE– [ 60] ENABLE –

500.0 Hz/s– [ 62] ACCEL LIMIT –

500.0 Hz/s– [ 61] DECEL LIMIT –

Slip Comp

FALSE – [ 82] ENABLE –

** 150.0 rpm – [ 85] MOTORING LIMIT –

** 150.0 rpm – [ 86] REGEN LIMIT –

Dynamic Braking

– BRAKING [ 81] – FALSE

TRUE – [ 80] ENABLE –

100 Ohm – [ 77] BRAKE RESISTANCE–

0.1 kW – [ 78] BRAKE POWER –

25 – [ 79] 1SEC OVER RATING–

Motor Control

Stabilisation

TRUE– [128] ENABLE –

Sequencing and Reference

Reference

SPEED DEMAND[255] –0.00 %

SPEED SETPOINT[254] –0.00 %

REVERSE[256] –FALSE

LOCAL SETPOINT[247] –0.00 %

LOCAL REVERSE[250] –FALSE

COMMS SETPOINT[770] –0.00 %

0.00 %– [245] REMOTE SETPOINT–

0.00 %– [248] SPEED TRIM –

110.00 %– [252] MAX SPEED CLAMP–

-110.00 %– [253] MIN SPEED CLAMP –

FALSE– [243] TRIM IN LOCAL –

FALSE– [249] REMOTE REVERSE –

Reference Jog

10.00 % – [246] SETPOINT –

1.0 s – [261] ACCEL TIME –

1.0 s – [262] DECEL TIME –

Reference Ramp

– RAMPING [698]– FALSE

LINEAR – [244] RAMP TYPE –

** 10.0 s – [258] ACCEL TIME –

** 10.0 s – [259] DECEL TIME –

FALSE – [268] SYMMETRIC MODE –

** 10.0 s – [267] SYMMETRIC TIME –

10.00 /s^2 – [692] SRAMP ACCEL –

10.00 /s^2 – [693] SRAMP DECEL –

10.00 /s^3 – [694] SRAMP JERK 1 –

10.00 /s^3 – [695] SRAMP JERK 2 –

10.00 /s^3 – [696] SRAMP JERK 3 –

10.00 /s^3 – [697] SRAMP JERK 4 –

TRUE – [691] SRAMP CONTINUOUS –

FALSE – [260] HOLD –

Reference Stop

STOP RAMP – [279] RUN STOP MODE –

10.0 s – [263] STOP TIME –

0.10 % – [266] STOP ZERO SPEED–

0.500 s – [284] STOP DELAY –

RAMPED – [304] FAST STOP MODE –

30.0 s – [275] FAST STOP LIMIT –

0.1 s – [264] FAST STOP TIME –

1200 Hz/s – [126] FINAL STOP RATE –

Auto Restart

– PENDING [608]– FALSE

– RESTARTING [616]– FALSE

– ATTEMPTS LEFT[614]– 5

– TIME LEFT [615]– 0.0 s

FALSE – [611] ENABLE –

5 – [612] ATTEMPTS –

10.0 s – [610] INITIAL DELAY 1 –

10.0 s – [613] ATTEMPT DELAY 1 –

0000 – [609] TRIGGERS 1 –

0000 – [744] TRIGGERS 1+ –

0.1 s – [678] INITIAL DELAY 2 –

0.1 s – [679] ATTEMPT DELAY 2 –

– [677] TRIGGERS 2 –

– [745] TRIGGERS 2+ –

0000

0.00 %

Setpoint Scale

– OUTPUT [ 59] – 0.0 Hz

– [ 58] INPUT –

** 1500 RPM– [1032] MAX SPEED –

Inverse Time

– IT LIMITING [1152]– FALSE

– INVERSE TIME OP [1153]– 0.00 %

105.00 % – [1148] AIMING POINT –

60.0 s – [1149] DELAY –

10.0 s – [1150] DOWN TIME –

120.0 s – [1151] UP TIME –

Motor Data

** VOLTS / HZ– [1157] CONTROL MODE –

** 5.50 kW– [1158] POWER –

** 50.0 Hz– [1159] BASE FREQUENCY –

** 400.0 V– [1160] MOTOR VOLTAGE –

** 11.30 A– [ 64] MOTOR CURRENT –

** 3.39 A– [ 65] MAG CURRENT –

** 1445.0 rpm– [ 83] NAMEPLATE RPM –

** STAR– [124] MOTOR CONNECTION–

** 4 – [ 84] MOTOR POLES –

** 0.90– [242] POWER FACTOR –

** 2.0 – [1164] OVERLOAD –

** 1.3625 Ohm– [119] STATOR RES –

** 43.37 mH– [120] LEAKAGE INDUC –

** 173.48 mH– [121] MUTUAL INDUC –

276.04 ms– [1163] ROTOR TIME CONST –

Current Limit

150.00 %

– [365] CURRENT LIMIT –

TRUE – [686] REGEN LIM ENABLE–

Flycatching

ACTIVE [576]

–

FALSE

SETPOINT [ 28]

–

0.00 %

FALSE– [570] ENABLE –

ALWAYS– [571] START MODE –

BIDIRECTIONAL

–

[572] SEARCH MODE

–

** 9.00 %– [573] SEARCH VOLTS –

** 40.00 %

–

[ 32] SEARCH BOOST

–

** 10.0 s– [574] SEARCH TIME –

5.0 Hz– [575] MIN SEARCH SPEED–

** 3.0 s

–

[709] REFLUX TIME

–

Inj Braking

ACTIVE [583]– FALSE

** 0.5 s– [710] DEFLUX TIME –

** 9.0 Hz– [577] FREQUENCY –

100.00 %

–

[578] I-LIM LEVEL

–

** 2.0 s

–

[579] DC PULSE

–

** 1.0 s

–

[580] FINAL DC PULSE

–

** 4.00 %

–

[581] DC LEVEL

–

600.0 s– [582] TIMEOUT –

** 100.00 %– [739] BASE VOLTS –

Torque Limit

– ACTUAL POS LIM [1212]– 0.00 %

– ACTUAL NEG LIM [1213]– 0.00 %

150.00 %

–

[1208] POS TORQUE LIM

–

-150.00 % – [1209] NEG TORQUE LIM –

150.00 % – [1210] MAIN TORQUE LIM –

150.00 % – [1554] FAST STOP T-LIM –

FALSE – [1211] SYMMETRIC LIM –

Energy Meter

– POWER [1604]– 0.00 kW

– POWER [1605]– 0.00 HP

–

REACTIVE POWER [1606]

–

0.00 kVAr

– ENERGY USED [1607]– 0.0 kWh

FALSE – [1603] RESET –

Feedbacks

– DC LINK VOLTS [ 75]– 0 V

–

TERMINAL VOLTS [1020]

–

0 V

– SPEED FEEDBACK

RPM

[569]– 0.00 rpm

–

SPEED FBK REV/S [568]

–

0.00 rev/s

– SPEED FEEDBACK % [749]– 0.00 %

– ENCODER FBK % [1238]– 0.00 %

– ENCODER COUNT[1016]– 0

– TORQUE FEEDBACK [ 70]– 0.00 %

– FIELD FEEDBACK [ 73]– 0.00 %

– MOTOR CURRENT % [ 66]– 0.00 %

– MOTOR CURRENT [ 67]– 0.0 A

** 10.0 V

–

[761] ENCODER SUPPLY

–

** 2048 – [566] ENCODER LINES –

**FALSE – [567] ENCODER INVERT –

QUADRATURE

–

[565] ENCODER MODE

**FALSE – [ 50] QUADRATIC TORQUE –

Fluxing

LINEAR LAW

–

[104] V/F SHAPE

–

* 50.0 Hz

–

[106] BASE FREQUENCY

–

** 0.00 %

–

[107] FIXED BOOST

–

** 0.00 %

–

[108] AUTO BOOST

–

0.00 % – [1656] ACCELRTN BOOST –

FALSE

–

[1655] ENERGY SAVING

–

10.00 % – [1657] USER FREQ 1 –

10.00 %

–

[1658] USER VOLTAGE 1

–

20.00 %

–

[1659] USER FREQ 2

–

20.00 %

–

[1660] USER VOLTAGE 2

–

30.00 % – [1661] USER FREQ 3 –

30.00 % – [1662] USER VOLTAGE 3 –

40.00 % – [1663] USER FREQ 4 –

40.00 % – [1664] USER VOLTAGE 4 –

50.00 %

–

[1665] USER FREQ 5

–

50.00 % – [1666] USER VOLTAGE 5 –

60.00 %

–

[1667] USER FREQ 6

–

60.00 %

–

[1668] USER VOLTAGE 6

–

70.00 %

–

[1669] USER FREQ 7

–

70.00 %

–

[1670] USER VOLTAGE 7

–

80.00 % – [1671] USER FREQ 8 –

80.00 % – [1672] USER VOLTAGE 8 –

90.00 % – [1673] USER FREQ 9 –

90.00 %

–

[1674] USER VOLTAGE 9

–

100.00 %

–

[1675] USER FREQ 10

–

100.00 %

–

[1676] USER VOLTAGE 10

–

Power Loss Cntrl

–

PWR LOSS ACTIVE [1271]

–

FALSE

–

[1265] ENABLE

–

** 447V

–

[1266] TRIP THRESHOLD

–

20V

–

[1267] CONTROL BAND

–

10.00s – [1268] ACCEL TIME –

5.00s

–

[1269] DECEL TIME

–

0.00%

–

[1677] INITIAL STEP

–

30.00s

–

[1270] TIME LIMIT

–

Regen Control

– SYNCHRONISING [1641]– FALSE

–

SYNCHRONISED [1642]

–

FALSE

–

PHASE LOSS [1643]

–

FALSE

–

CLOSE PRECHARGE [1644]

–

FALSE

– ENABLE DRIVE [1645]– FALSE

–

STATUS [1646]

–

SUPPLY FREQ LOW

TRUE

–

[1633] PRECHARGE CLOSED

–

720V – [1634] DC VOLTS DEMAND –

FALSE

–

[1678] BRAKE MODE

–

Sequencing Logic

– TRIPPED [289] – FALSE

– RUNNING [285] – FALSE

–

JOGGING [302]

–

FALSE

– STOPPING [303] – FALSE

–

OUTPUT CONTACTOR [286]

–

FALSE

–

SWITCH ON ENABLE [288]

–

FALSE

– SWITCHED ON [306] – FALSE

–

READY [287]

–

FALSE

–

SYSTEM RESET [305]

–

FALSE

–

SEQUENCER STATE [301]

–

START DISABLED

–

REMOTE REV OUT [296]

–

FALSE

– HEALTHY [274] – TRUE

– FAN RUNNING [620] – FALSE

0.000s

–

[1686] START DELAY

–

FALSE

–

[291] RUN FORWARD

–

FALSE

–

[292] RUN REVERSE

–

FALSE

–

[293] NOT STOP

–

FALSE – [280] JOG –

TRUE – [1235] CONTACTOR CLOSED –

TRUE

–

[276] DRIVE ENABLE

–

TRUE – [277] NOT FAST STOP –

TRUE

–

[278] NOT COAST STOP

–

FALSE – [294] REMOTE REVERSE –

FALSE – [282] REM TRIP RESET –

TRUE

–

[290] TRIP RST BY RUN

–

FALSE

–

[283] POWER UP START

–

Voltage Control

NONE – [595] VOLTAGE MODE –

100.00 %

–

[112] BASE VOLTS

–

Speed Loop

– TOTAL SPD DMD RPM [1203] – 0.00 RPM

– TOTAL SPD DMD % [1206] – 0.00 %

– SPEED ERROR [1207] – 0.00 %

– TORQUE DEMAND [1204] – 0.00 %

–

DIRECT INPUT [1205]

–

0.00 %

– PHASE INPUT [1397] – 0.00 %

** 20.00

–

[1187] SPEED PROP GAIN

–

** 100 ms

–

[1188] SPEED INT TIME

–

FALSE – [1189] INT DEFEAT –

0.00 %

–

[1190] SPEED INT PRESET

–

3.0 ms

–

[1191] SPEED DMD FILTER

–

1.5 ms – [1192] SPEED FBK FILTER –

0.00 %

–

[1193] AUX TORQUE DMD

–

0.00 %

–

[1194] ADAPTIVE THRESH

–

0.00 – [1195] ADAPTIVE P-GAIN –

NONE – [1196] DIRECT IP SELECT –

1.0000

–

[1197] DIRECT RATIO

–

110.00 % – [1198] DIRCT IP POS LIM –

-110.00 % – [1199] DIRCT IP NEG LIM –

110.00 % – [1200] SPEED POS LIM –

-110.00 % – [1201] SPEED NEG LIM –

FALSE – [1202] TORQ DMD ISOLATE –

Macro Control Blocks

Some of these blocks may already be in use by the macros
