Application Macros 5-24
690+ Series Frequency Inverter
Brake Control
– RELEASE [589] – FALSE
– HOLD [590] – FALSE
50.00 % – [584] ON LOAD –
5.0 Hz – [585] ON FREQUENCY –
3.0 Hz – [586] OFF FREQUENCY –
0.00 s – [587] ON HOLD TIME –
0.00 s – [588] OFF HOLD TIME –
Linear Ramp
– OUTPUT [887] – 0.00 %
– RAMPING [888] – FALSE
0.00 % – [879] INPUT –
10.0 s – [880] ACCEL TIME –
10.0 s – [881] DECEL TIME –
FALSE – [882] SYMMETRIC MODE –
10.0 s – [883] SYMMETRIC TIME –
FALSE – [884] HOLD –
FALSE – [885] RESET –
0.00 % – [886] RESET VALUE –
Preset 1
OUTPUT 1 [356] – 0.00
OUTPUT 2 [372] – 0.00
INPUT 0 – [355] SELECT INPUT –
0.00 – [347] INPUT 0 –
0.00 – [348] INPUT 1 –
0.00 – [349] INPUT 2 –
0.00 – [350] INPUT 3 –
0.00 – [351] INPUT 4 –
0.00 – [352] INPUT 5 –
0.00 – [353] INPUT 6 –
0.00 – [354] INPUT 7 –
Preset 3
OUTPUT 1 [399] – 0.00
OUTPUT 2 [374] – 0.00
INPUT 0 – [398] SELECT INPUT –
0.00 – [390] INPUT 0 –
0.00 – [391] INPUT 1 –
0.00 – [392] INPUT 2 –
0.00 – [393] INPUT 3 –
0.00 – [394] INPUT 4 –
0.00 – [395] INPUT 5 –
0.00 – [396] INPUT 6 –
0.00 – [397] INPUT 7 –
Preset 5
OUTPUT 2 [530] – 0.00
OUTPUT 2 [531] – 0.00
INPUT 0 – [529] SELECT INPUT –
0.00 – [521] INPUT 0 –
0.00 – [522] INPUT 1 –
0.00 – [523] INPUT 2 –
0.00 – [524] INPUT 3 –
0.00 – [525] INPUT 4 –
0.00 – [526] INPUT 5 –
0.00 – [527] INPUT 6 –
0.00 – [528] INPUT 7 –
Preset 7
OUTPUT 1 [552] – 0.00
OUTPUT 2 [553] – 0.00
INPUT 0 – [551] SELECT INPUT –
0.00 – [543] INPUT 0 –
0.00 – [544] INPUT 1 –
0.00 – [545] INPUT 2 –
0.00 – [546] INPUT 3 –
0.00 – [547] INPUT 4 –
0.00 – [548] INPUT 5 –
0.00 – [549] INPUT 6 –
0.00 – [550] INPUT 7 –
Preset 2
OUTPUT 1 [389] – 0.00
OUTPUT 2 [373] – 0.00
INPUT 0 – [388] SELECT INPUT –
0.00 – [380] INPUT 0 –
0.00 – [381] INPUT 1 –
0.00 – [382] INPUT 2 –
0.00 – [383] INPUT 3 –
0.00 – [384] INPUT 4 –
0.00 – [385] INPUT 5 –
0.00 – [386] INPUT 6 –
0.00 – [387] INPUT 7 –
Preset 4
OUTPUT 1 [519] – 0.00
OUTPUT 2 [520] – 0.00
INPUT 0 – [518] SELECT INPUT –
0.00 – [510] INPUT 0 –
0.00 – [511] INPUT 1 –
0.00 – [512] INPUT 2 –
0.00 – [513] INPUT 3 –
0.00 – [514] INPUT 4 –
0.00 – [515] INPUT 5 –
0.00 – [516] INPUT 6 –
0.00 – [517] INPUT 7 –
Preset 6
OUTPUT 1 [541] – 0.00
OUTPUT 2 [542] – 0.00
INPUT 0 – [540] SELECT INPUT –
0.00 – [532] INPUT 0 –
0.00 – [533] INPUT 1 –
0.00 – [534] INPUT 2 –
0.00 – [535] INPUT 3 –
0.00 – [536] INPUT 4 –
0.00 – [537] INPUT 5 –
0.00 – [538] INPUT 6 –
0.00 – [539] INPUT 7 –
Preset 8
OUTPUT 1 [563] – 0.00
OUTPUT 2 [564] – 0.00
INPUT 0 – [562] SELECT INPUT –
0.00 – [554] INPUT 0 –
0.00 – [555] INPUT 1 –
0.00 – [556] INPUT 2 –
0.00 – [557] INPUT 3 –
0.00 – [558] INPUT 4 –
0.00 – [559] INPUT 5 –
0.00 – [560] INPUT 6 –
0.00 – [561] INPUT 7 –
Raise/Lower
OUTPUT [325] – 0.00 %
FALSE – [327] RAISE INPUT –
FALSE – [328] LOWER INPUT –
10.0 s – [326] RAMP TIME –
100.00 % – [330] MAX VALUE –
-100.00 % – [329] MIN VALUE –
0.00 % – [331] RESET VALUE –
FALSE – [332] RESET –
PID
PID OUTPUT [320] – 0.00 %
PID ERROR [766] – 0.00 %
0.00 % – [310] SETPOINT –
0.00% – [764] FEEDBACK –
FALSE – [763] SETPOINT NEGATE –
FALSE – [765] FEEDBACK NEGATE –
FALSE – [311] ENABLE –
FALSE – [312] INTEGRAL DEFEAT –
1.0 – [313] P GAIN –
1.00 s – [314] I TIME CONST –
0.000 s – [315] D TIME CONST –
0.100 s – [316] FILTER TC –
100.00 % – [317] OUTPUT POS LIMIT –
-100.00 % – [318] OUTPUT NEG LIMIT –
1.0000 – [319] OUTPUT SCALING –
S-Ramp
– OUTPUT [767] – 0.00 %
– RAMPING [768] – FALSE
0.00 % – [889] INPUT –
10.00 /s^2 – [894] ACCELERATION –
10.00 /s^2 – [895] DECELERATION –
10.00 /s^3 – [890] JERK 1 –
10.00 /s^3 – [891] JERK 2 –
10.00 /s^3 – [892] JERK 3 –
10.00 /s^3 – [893] JERK 4 –
FALSE – [899] CONTINUOUS –
FALSE – [896] HOLD –
FALSE – [897] RESET –
0.00 – [898] RESET VALUE –
Trips History
TRIP 1 (NEWEST [500] – NO TRIP
TRIP 2 [501] – NO TRIP
TRIP 3 [502] – NO TRIP
TRIP 4 [503] – NO TRIP
TRIP 5 [504] – NO TRIP
TRIP 6 [505] – NO TRIP
TRIP 7 [506] – NO TRIP
TRIP 8 [507] – NO TRIP
TRIP 9 [508] – NO TRIP
TRIP 10 (OLDEST [509] – NO TRIP
Setpoint Functions Trips
Hoist/Lift
Trips Status
ACTIVE TRIPS [ 4] – 0000
ACTIVE TRIPS+ [740] – 0000
WARNINGS [ 5] – 0000
WARNINGS+ [741] – 0000
FIRST TRIP [ 6] – NO TRIP
0700 – [231] DISABLED TRIPS –
0040 – [742] DISABLED TRIPS+ –
Minimum Speed
OUTPUT [335] – 0.00 %
0.00 % – [336] INPUT –
-100.00 % – [337] MINIMUM –
PROP. W/MIN. – [338] MODE –
Skip Frequencies
OUTPUT [346] – 0.00 %
OUTPUT HZ [363] – 0.0 Hz
INPUT HZ [362] – 0.0 Hz
0.00 % – [340] INPUT –
0.0 Hz – [341] BAND 1 –
0.0 Hz – [342] FREQUENCY 1 –
0.0 Hz – [680] BAND 2 –
0.0 Hz – [343] FREQUENCY 2 –
0.0 Hz – [681] BAND 3 –
0.0 Hz – [344] FREQUENCY 3 –
0.0 Hz – [682] BAND 4 –
0.0 Hz – [345] FREQUENCY 4 –
Filter 1
– OUTPUT [1104] – 0.00 %
0.00 % – [1101] INPUT –
FALSE – [1102] RESET –
1.00 s – [1103] TIME CONSTANT –
Filter 2
– OUTPUT [1108] – 0.00 %
0.00 % – [1105] INPUT –
FALSE – [1106] RESET –
1.00 s – [1107] TIME CONSTANT –
Zero Speed
– AT ZERO SPD FBK [1233] – TRUE
– AT ZERO SPD DMD [360] – TRUE
– AT STANDSTILL [1234] – TRUE
0.00 % – [359] HYSTERISIS –
0.00 % – [357] THRESHOLD –
PID (Type 2)
OUTPUT [1256]
–
0.00 %
LIMITING [1257]
–
FALSE
0.00 % – [1247] ERROR
–
0.00% – [1248] FEED FWD –
1.00
–
[1249] FEED FWD GAIN
–
0.10
–
[1250] P GAIN
–
1.0
–
[1251] I GAIN
–
0.00
–
[1252] D GAIN
–
300.00%
–
[1253] LIMIT
–
FALSE
–
[1254] ENABLE
–
0.05 s
–
[1255] D FILTER TC
–
I/O Trips
–
THERMIST [1155]
–
FALSE
–
ENCODER TB [1156]
–
FALSE
–
EXTERNAL [234]
–
FALSE
FALSE
–
[760] INVERT THERMIST
–
FALSE
–
[1154] INVERT ENC TRIP
–
TRIP
–
[233] EXT TRIP MODE
–
FALSE
–
[235] INPUT 1 BREAK
–
FALSE
–
[236] INPUT 2 BREAK
–
Communications
Tec Option
FAULT [756] – NONE
VERSION [757] – 0000
OUTPUT 1 [758] – 0000
OUTPUT 2 [759] – 0000
NONE – [750] TYPE –
0 – [751] INPUT 1 –
0 – [752] INPUT 2 –
0 – [753] INPUT 3 –
0 – [754] INPUT 4 –
0 – [755] INPUT 5 –
System Port (P3)
EI ASCII – [117] MODE –
0 – [102] GROUP ID (GID)
–
0 – [103] UNIT ID (UID) –
5703 Input
–
SCALED VALUE [1260]
–
0.00
– RAW VALUE [1261] – 0.00
– BREAK [1262] – FALSE
1.0000 – [1258] RATIO –
FALSE
–
[1259] NEGATE
–
5703 Output
0.00 – [1263] VALUE –
FALSE – [1264] REPEATER –
STALL TRIP
480.0 s
–
[241] STALL TIME
–
TORQUE – [1208] STALL LIMIT TYPE
–
Spd Fbk Trip
–
TRIPPED [1650]
–
FALSE
FALSE
–
[1648] INHIBIT
–
50.00 %
–
[1649] THRESHOLD
–
10.00 s
–
[1647] DELAY
–
Macro Control Blocks
Some of these blocks may already be in use by the macros
