Parker 690+ series - PATTERN GEN

1-62 Programming Your Application
690+ Series Frequency Inverter
PATTERN GEN
Designed for all Motor Control Modes.
The pattern generator function block allows
you to configure the Inverter PWM (Pulse
Width Modulator) operation.
Functional Description
The Inverter provides a unique quiet pattern PWM strategy in order to reduce audible motor
noise. The user is able to select between the quite pattern or the more conventional fixed carrier
frequency method. With the quiet pattern strategy selected (random pattern enabled), audible
motor noise is reduced to a dull hiss.
In addition, the user is able to select the PWM carrier frequency. This is the main switching
frequency of the power output stage of the Frequency Inverter. A high setting of carrier
frequency (e.g. 6kHz) reduces audible motor noise but only at the expense of higher Inverter
losses and smooth motor rotation at low output frequencies. A low setting of carrier frequency
(e.g. 3kHz), reduces Inverter losses but increases audible motor noise.
Pattern Gen
–
DRIVE FREQUENCY [591]
–
0.00 Hz
TRUE
–
[ 98] RANDOM PATTERN
–
3 kHz
–
[ 99] FREQ SELECT
–
** 2.0 s
–
[100] DEFLUX DELAY
–
MMI Menu Map
1
SETUP
2
MOTOR CONTROL
3
PATTERN GEN
RANDOM PATTERN
FREQ SELECT
DEFLUX DELAY
DRIVE FREQUENCY
Parameter Descriptions
RANDOM PATTERN
Range: FALSE / TRUE
This parameter selects between random pattern (quiet motor noise) or the more conventional
fixed carrier PWM strategies. When TRUE, random pattern is enabled.
FREQ SELECT
Range: Enumerated - see below
This parameter selects the base switching frequency of the output power stack. The choices of
switching frequency are:
Enumerated Value : Frequency
0 : 3 kHz
1 : 6 kHz
2 : 9kHz
Note: The highest selectable frequency is product dependent
The higher the switching frequency, the lower the level of motor audible noise. However, this is
only achieved at the expense of increased Inverter losses.
Refer also to “Quadratic/Constant Torque Selection”, page 1-
136.
DEFLUX DELAY
Range: 0.1 to 10.0 s
Sets the minimum allowed delay between disabling and then re-enabling PWM production (i.e.
stopping and starting the drive).
DRIVE FREQUENCY
Range: —.x Hz
The Inverter output frequency.
