1-12 Programming Your Application
690+ Series Frequency Inverter
ANALOG OUTPUT
The analog output blocks converts the demand percentage into a form suitable for driving the
analog output electronics of the Inverter.
Analog Output 1
0.00 %
–
[ 45] VALUE
–
100.00 %
–
[ 46] SCALE
–
0.00 %
–
[ 47] OFFSET
–
TRUE
–
[ 48] ABSOLUTE
–
0..+10 V
–
[ 49] TYPE
–
Analog Output 3
0.00 %
–
[800] VALUE
–
100.00 %
–
[801] SCALE
–
0.00 %
–
[802] OFFSET
–
FALSE
–
[803] ABSOLUTE
–
0..+10 V
–
[804] TYPE
–
MMI Menu Map
1
SETUP
2
INPUTS & OUTPUTS
3
A
NALOG OUTPUT
4
A
NALOG OUTPUT 1
4
A
NALOG OUTPUT 2
4
A
NALOG OUTPUT 3
VALUE
SCALE
OFFSET
ABSOLUTE
TYPE
Analog Output 2
0.00 %
–
[731] VALUE
–
100.00 %
–
[732] SCALE
–
0.00 %
–
[733] OFFSET
–
FALSE
–
[734] ABSOLUTE
–
0..+10 V
–
[735] TYPE
–
Parameter Descriptions
VALUE
Range: -300.00 to 300.00 %
The demanded value to output.
SCALE
Range: -300.00 to 300.00 %
A scaling factor to apply to VALUE . A scaling factor of 100.00% has no effect.
OFFSET
Range: -300.00 to 300.00 %
An offset added to VALUE after the scaling factor has been applied. An offset factor of 0.00%
has no effect.
ABS
Range: FALSE / TRUE
When true the output sign is ignored.
TYPE
Range: Enumerated - see below
The output hardware type, either Volts or Amps.
• ANALOG OUTPUT 1 supports all types, except -10..+10V.
• ANALOG OUTPUT 2 and ANALOG OUTPUT 3 are used as voltage outputs only.
An incorrect selection will force the VALUE to be set to zero.
Enumerated Value : Type
0 : 0..+10 V
1 : 0..20 mA
2 : 4..20 mA
3 : -10..+10 V
4 : 20..4 mA
5 : 20..0 mA
6 : +2..+10 V
7 : 0..+5 V
8 : +1..+5 V
