Parker 690+ series User Manual

Programming Your Application 1-123
690+ Series Frequency Inverter
TRIPS HISTORY
This function block records the last ten trips
that caused the Inverter to stop.
To do this, it stores the value of the FIRST
TRIP parameter, tag number 6, taken from
the TRIPS STATUS function block.
Functional Description
This function block provides a view of the ten most recent trips that caused the Inverter to stop.
Every time a new trip occurs this is entered as TRIP 1 (NEWEST and the other recorded trips
are moved down. If more than ten trips have occurred since the Inverter was configured then
only the ten most recent trips will be available for inspection.
These parameters are preserved through a power failure.
Trips History
TRIP 1 (NEWEST [500]
–
NO TRIP
TRIP 2 [501]
–
NO TRIP
TRIP 3 [502]
–
NO TRIP
TRIP 4 [503]
–
NO TRIP
TRIP 5 [504]
–
NO TRIP
TRIP 6 [505]
–
NO TRIP
TRIP 7 [506]
–
NO TRIP
TRIP 8 [507]
–
NO TRIP
TRIP 9 [508]
–
NO TRIP
TRIP 10 (OLDEST [509]
–
NO TRIP
MMI Menu Map
1
SETUP
2
TRIPS
3
TRIPS HISTORY
TRIP 1 (NEWEST)
TRIP 2
TRIP 3
TRIP 4
TRIP 5
TRIP 6
TRIP 7
TRIP 8
TRIP 9
TRIP 10 (OLDEST)
Parameter Descriptions
TRIP 1 (NEWEST)
Range: Enumerated
Records the most recent trip that caused the Inverter to stop. The values that this (and the
parameters below) may take are the same as tag number 6, FIRST TRIP, detailed in the TRIPS
STATUS function block.
TRIP 2
Range: As above
Records the second most recent trip that caused the Inverter to stop.
TRIP 3
Range: As above
Records the third most recent trip that caused the Inverter to stop.
TRIP 4
Range: As above
Records the fourth most recent trip that caused the Inverter to stop.
TRIP 5
Range: As above
Records the fifth most recent trip that caused the Inverter to stop.
TRIP 6
Range: As above
Records the sixth most recent trip that caused the Inverter to stop.
TRIP 7
Range: As above
Records the seventh most recent trip that caused the Inverter to stop.
TRIP 8
Range: As above
Records the eighth most recent trip that caused the Inverter to stop.
TRIP 9
Range: As above
Records the ninth most recent trip that caused the Inverter to stop.
TRIP 10 (OLDEST)
Range: As above
Records the tenth most recent trip that caused the Inverter to stop.
