2-2 Parameter Specification
690+ Series Frequency Inverter
Specification Table:
Tag Name Order
TAG MMI Name Block
1835 1mS CYCLE RATE PHASE CONFIGURE
79 1SEC OVER RATING DYNAMIC BRAKING
1695 ABOVE THRESHOLD TIMER 1
1825 ABOVE THRESHOLD TIMER 2
48 ABSOLUTE ANALOG OUTPUT 1
734 ABSOLUTE ANALOG OUTPUT 2
803 ABSOLUTE ANALOG OUTPUT 3
62 ACCEL LIMIT SLEW RATE LIMIT
880 ACCEL TIME LINEAR RAMP
1268 ACCEL TIME POWER LOSS CNTRL
261 ACCEL TIME REFERENCE JOG
258 ACCEL TIME REFERENCE RAMP
1499 ACCELERATION PHASE MOVE
1569 ACCELERATION PHASE REGISTER
894 ACCELERATION S-RAMP
1656 ACCELRTN BOOST FLUXING
604 ACTIVE AUTOTUNE
576 ACTIVE FLYCATCHING
1469 ACTIVE HOME
583 ACTIVE INJ BRAKING
1503 ACTIVE PHASE INCH
1509 ACTIVE PHASE MOVE
1512 ACTIVE PHASE OFFSET
1478 ACTIVE PHASE TUNING
4 ACTIVE TRIPS TRIPS STATUS
740 ACTIVE TRIPS+ TRIPS STATUS
1294 ACTUAL TYPE SYSTEM OPTION
1195 ADAPTIVE P-GAIN SPEED LOOP
1194 ADAPTIVE THRESH SPEED LOOP
1500 ADVANCE PHASE INCH
1148 AIMING POINT INVERSE TIME
1234 AT STANDSTILL ZERO SPEED
360 AT ZERO SPD DMD ZERO SPEED
1233 AT ZERO SPD FBK ZERO SPEED
613 ATTEMPT DELAY 1 AUTO RESTART
679 ATTEMPT DELAY 2 AUTO RESTART
612 ATTEMPTS AUTO RESTART
614 ATTEMPTS LEFT AUTO RESTART
108 AUTO BOOST FLUXING
1193 AUX TORQUE DMD SPEED LOOP
341 BAND 1 SKIP FREQUENCIES
680 BAND 2 SKIP FREQUENCIES
681 BAND 3 SKIP FREQUENCIES
682 BAND 4 SKIP FREQUENCIES
1159 BASE FREQUENCY MOTOR DATA
739 BASE VOLTS INJ BRAKING
845 BOOST TAPER CALC
840 BOOST ENABLE TAPER CALC
1678 BRAKE MODE REGEN CNTRL
78 BRAKE POWER DYNAMIC BRAKING
77 BRAKE RESISTANCE DYNAMIC BRAKING
81 BRAKING DYNAMIC BRAKING
1262 BREAK 5703 INPUT
18 BREAK ANALOG INPUT 1
27 BREAK ANALOG INPUT 2
717 BREAK ANALOG INPUT 3
724 BREAK ANALOG INPUT 4
12 BREAK ENABLE ANALOG INPUT 1
TAG MMI Name Block
21 BREAK ENABLE ANALOG INPUT 2
711 BREAK ENABLE ANALOG INPUT 3
718 BREAK ENABLE ANALOG INPUT 4
17 BREAK VALUE ANALOG INPUT 1
26 BREAK VALUE ANALOG INPUT 2
716 BREAK VALUE ANALOG INPUT 3
723 BREAK VALUE ANALOG INPUT 4
1644 CLOSE PRECHARGE REGEN CNTRL
321 COEFFICIENT A DISPLAY SCALE 1
375 COEFFICIENT A DISPLAY SCALE 2
854 COEFFICIENT A DISPLAY SCALE 3
862 COEFFICIENT A DISPLAY SCALE 4
44 COEFFICIENT B DISPLAY SCALE 1
673 COEFFICIENT B DISPLAY SCALE 2
855 COEFFICIENT B DISPLAY SCALE 3
863 COEFFICIENT B DISPLAY SCALE 4
322 COEFFICIENT C DISPLAY SCALE 1
376 COEFFICIENT C DISPLAY SCALE 2
856 COEFFICIENT C DISPLAY SCALE 3
864 COEFFICIENT C DISPLAY SCALE 4
273 COMMS COMMAND COMMS CONTROL
270 COMMS REF COMMS CONTROL
295 COMMS SEQ COMMS CONTROL
770 COMMS SETPOINT REFERENCE
272 COMMS STATUS COMMS CONTROL
309 COMMS TIMEOUT COMMS CONTROL
817 COMPENSATIONS COMPENSATION
339 CONFIG NAME ACCESS CONTROL
1235 CONTACTOR CLOSED SEQUENCING LOGIC
899 CONTINUOUS S-RAMP
1267 CONTROL BAND POWER LOSS CNTRL
1157 CONTROL MODE MOTOR DATA
826 CORE 1 DIAMETER CALC
827 CORE 2 DIAMETER CALC
1631 CORRECTION GAIN PHASE REGISTER
1465 CORRECTION LIMIT HOME
1570 CORRECTIONS PHASE REGISTER
1526 COUNTS PER UNIT PHASE CONFIGURE
1684 COUNTS PER UNIT POSITION
834 CURRENT CORE DIAMETER CALC
843 CURRENT CORE TAPER CALC
365 CURRENT LIMIT CURRENT LIMIT
1521 D FILTER TC PHASE PID
1255 D FILTER TC PID (TYPE 2)
1518 D GAIN PHASE PID
1252 D GAIN PID (TYPE 2)
315 D TIME CONSTANT PID
581 DC LEVEL INJ BRAKING
75 DC LINK VOLTS FEEDBACKS
579 DC PULSE INJ BRAKING
1634 DC VOLTS DEMAND REGEN CNTRL
1466 DECEL LIMIT HOME
61 DECEL LIMIT SLEW RATE LIMIT
881 DECEL TIME LINEAR RAMP
1269 DECEL TIME POWER LOSS CNTRL
262 DECEL TIME REFERENCE JOG
259 DECEL TIME REFERENCE RAMP
1468 DECELERATION HOME
895 DECELERATION S-RAMP
334 DECIMAL PLACE DISPLAY SCALE 1
379 DECIMAL PLACE DISPLAY SCALE 2
852 DECIMAL PLACE DISPLAY SCALE 3
860 DECIMAL PLACE DISPLAY SCALE 4
100 DEFLUX DELAY PATTERN GEN
710 DEFLUX TIME INJ BRAKING
