1-118 Programming Your Application
690+ Series Frequency Inverter
TEC OPTION
This function block is used to configure the
various Technology Options that can be fitted.
The Technology Option provides a
communications interface for external control
of the Inverter.
If a Technology Option is present when
defaults are loaded, the TYPE parameter is
automatically set. The parameter names
change when the selection for the TYPE
parameter matches the Technology Option
fitted.
Refer to the appropriate Technology Option
Technical Manual supplied with the option for further details.
Tec Option
FAULT [756]
–
NONE
VERSION [757]
–
0000
OUTPUT 1 [758]
–
0000
OUTPUT 2 [759]
–
0000
NONE – [750] TYPE –
0
–
[751] INPUT 1
–
0
–
[752] INPUT 2
–
0
–
[753] INPUT 3
–
0
–
[754] INPUT 4
–
0
–
[755] INPUT 5
–
MMI Menu Map
1
SETUP
2
COMMUNICATIONS
3
TEC OPTION
TYPE
INPUT 1
INPUT 2
INPUT 3
INPUT 4
INPUT 5
FAULT
VERSION
OUTPUT 1
Parameter Descriptions
TYPE
Range: Enumerated - see below
Selects the type of Technology Option.
Enumerated Value : Technology Option
0 : NONE
1 : RS485
2 : PROFIBUS
3 : LINK
4 : DEVICE NET
5 : CAN OPEN
6 : LONWORKS
7 : CONTROLNET
8 : MODBUS PLUS
9 : ETHERNET
10 : TYPE 10
11 : TYPE 11
12 : TYPE 12
13 : TYPE 13
14 : TYPE 14
15 : TYPE 15
INPUT 1 to INPUT 5
Range: -32768 to 32767
The use of these input parameters depends on the type of Technology Option fitted.
Refer to the Technology Option Technical Manual.
FAULT
Range: Enumerated - see below
The fault state of the Technology Option.
Enumerated Value : Fault State
0 : NONE
1 : PARAMETER VALUE
2 : TYPE MISMATCH
3 : SELFTEST
4 : HARDWARE
5 : MISSING
VERSION
Range: 0x0000 to 0xFFFF
The version of the Technology Option. If no option is fitted then the version is reset to zero.
OUTPUT 1 and OUTPUT 2
Range: 0x0000 to 0xFFFF
The use of these output parameters depends on the type of Technology Option fitted.
Refer to the Technology Option Technical Manual.
