1-112 Programming Your Application
690+ Series Frequency Inverter
STALL TRIP
The function block protects the motor from
damage that may be caused by continuous
operation beyond specification.
Functional Description
If STALL LIMIT TYPE is set to TORQUE and the estimated load exceeds the active TORQUE
LIMIT (refer to the TORQUE LIMIT function block) for a time greater than STALL TIME then
the stall trip will become active. The timer is reset whenever the estimated load is less than the
active Torque Limit.
Similarly, if the STALL LIMIT TYPE is set to CURRENT and the measured current exceeds the
active Current limit (i.e. the drive is in current limit) for a time greater than STALL TIME then
the stall trip will become active. The timer is reset whenever the measured current is less than the
active Current Limit.
Refer to the Installation Product Manual, Chapter 6 for a description of the trips supported by the
Inverter.
MMI Menu Map
1
SETUP
2
TRIPS
3
STALL TRIP
STALL TIME
STALL LIMIT TYPE
STALL TRIP
480.0 s
–
[241] STALL TIME
–
TORQUE – [1208] STALL LIMIT TYPE
–
Parameter Descriptions
STALL TIME
Range: 0.1 to 3000.0 s
The time after which a stall condition will cause a trip.
STALL LIMIT TYPE
Range:
This parameter determines whether the stall trip operates on motor torque or motor current.
Enumerated Value : Stall Limit Type
0 : TORQUE
1 : CURRENT
