Parker 690+ series - Multiplexer

Programming Your Application 1-57
690+ Series Frequency Inverter
MULTIPLEXER
Each block collects together 16 Boolean input values into a single word.
For example, one may be used to set and clear individual bits within a word such as the
TRIGGERS 1 word for the AUTO RESTART function block.
MMI Menu Map
1
SETUP
2
MISCELLANEOUS
3
MULTIPLEXER
4
MULTIPLEXER 1
4
MULTIPLEXER 2
INPUT 0
INPUT 1
INPUT 2
INPUT 3
INPUT 4
INPUT 5
INPUT 6
INPUT 7
INPUT 8
INPUT 9
INPUT 10
INPUT 11
INPUT 12
INPUT 13
INPUT 14
INPUT 15
OUTPUT
Multiplexer 2
OUTPUT [873]
–
0000
FALSE – [771] INPUT 0
–
FALSE
–
[772] INPUT 1
–
FALSE
–
[773] INPUT 2
–
FALSE
–
[792] INPUT 3
–
FALSE
–
[793] INPUT 4
–
FALSE
–
[794] INPUT 5
–
FALSE
–
[795] INPUT 6
–
FALSE
–
[796] INPUT 7
–
FALSE
–
[797] INPUT 8
–
FALSE
–
[798] INPUT 9
–
FALSE
–
[799] INPUT 10
–
FALSE
–
[868] INPUT 11
–
FALSE
–
[869] INPUT 12
–
FALSE
–
[870] INPUT 13
–
FALSE
–
[871] INPUT 14
–
FALSE
–
[872] INPUT 15
–
Multiplexer 1
OUTPUT [598]
–
0000
FALSE – [641] INPUT 0
–
FALSE
–
[642] INPUT 1
–
FALSE
–
[643] INPUT 2
–
FALSE
–
[644] INPUT 3
–
FALSE
–
[645] INPUT 4
–
FALSE
–
[646] INPUT 5
–
FALSE
–
[647] INPUT 6
–
FALSE
–
[648] INPUT 7
–
FALSE
–
[649] INPUT 8
–
FALSE
–
[650] INPUT 9
–
FALSE
–
[651] INPUT 10
–
FALSE
–
[652] INPUT 11
–
FALSE
–
[653] INPUT 12
–
FALSE
–
[654] INPUT 13
–
FALSE
–
[655] INPUT 14
–
FALSE
–
[656] INPUT 15
–
Parameter Descriptions
INPUT 0 TO INPUT 15
Range: FALSE / TRUE
The Boolean inputs to be assembled into a single word.
OUTPUT
Range: 0x0000 to 0xFFFF
The resulting word.
