Programming Your Application 1-37

690+ Series Frequency Inverter

FILTER

This function block contains two, simple order filters of the type:

1 + ST

MMI Menu Map

SETUP

SETPOINT FUNCS

FILTER

FILTER 1

FILTER 2

INPUT

RESET

TIME CONSTANT

OUTPUT

Parameter Descriptions

INPUT

Range: -300.00 to 300.00 %

Filter input.

RESET

Range: FALSE / TRUE

If TRUE, the output is set equal to the input and the filter is disabled.

TIME CONSTANT

Range: 0.00 to 300.00 s

Time constant. If less than 0.05s the filter is disabled.

OUTPUT

Range: —.00 %

Filtered output.

Filter 1

–

OUTPUT [1104]

–

0.00 %

–

[1101] INPUT

–

FALSE

–

[1102] RESET

–

1.00 s

–

[1103] TIME CONSTANT

–

Filter 2

–

OUTPUT [1108]

–

0.00 %

–

[1105] INPUT

–

FALSE

–

[1106] RESET

–

1.00 s

–

[1107] TIME CONSTANT

–
