For machines which use the "Separate Front and Rear Table Air Bed" option,
you can separately select the air bed for the front and rear tables (see menu
section 33/34: left column for the front table; right column for the rear table).
Otherwise, the rear-table air bed will correspond to the air bed of the entire
machine.
AWR (optional) (AWR = automatic waste removal)
The preset time determines for how long the front table will stay open after the auto-
matic pushout stroke to ensure proper discharge of the cutting waste before the table is
closed again.
Measuring system test
Whenever you power up the machine, the measuring system will be automatically
tested.
If any deviations are detected the "Please calibrate" message will be raised.
Operator's calibration
• To calibrate the measuring system: Press the "Operator's Calibration" button in the
"Settings" menu.
- If the backgauge is located before the 200 mm mark, it will slowly move back-
ward during the calibration process until it reaches calibration range sensor B39
and the zero pulse, stop at this position and reset the measuring system.
- If the backgauge is located behind the 200 mm mark, it will slowly move
backward during the calibration process for some 200 mm, reverse and move
slowly forward until it reaches calibration range sensor B39 and the zero pulse,
stop at this position and reset the measuring system.
Factory calibration
During "Factory Calibration", the rear table length is measured to determine the machine
size, for example, to read in the machine parameters after the first installation of a control
module.
Clear the entire machine table prior to factory calibration.
