Perfecta 115 TS - Page 94

Service Manual 13 Errors
13.2 Error messages
1/09 PERFECTA 115 / 132 / 168 / 225 – TS 94
PERFECTA Schneidemaschinenwerk GmbH  D-02625 Bautzen  Schäfferstr. 44  Tel.: +49-3591-556-131 to -133  Fax: +49 3591-556-139
Error Message Text Remarks
30
Error Flow switch S60 or
contactor K64 (B60 valve
monitoring) doesn't switch
ON
- Monitoring sensor B60 does not switch on.
31
Error Flow switch S60 or
contactor K64 (B61 valve
monitoring) doesn't switch
OFF
- Monitoring sensor B61 does not switch off.
32
Error Flow switch S60 or
contactor K64 (B61 valve
monitoring) doesn't switch
ON
- Monitoring sensor B61 does not switch on.
33
Error Stock not free although
the clamping contactors OFF
- S29 does not switch off.
34
Error Stock free signal al-
though safety module reports
"Pressure" ON
- S29 does not switch on.
35
Error No "Pressure" although
Clamping contactors are ON
- S6/K64 does not switch on.
36
Error "Pressure" ON although
Clamping contactors are OFF
- S60/K64 does not switch on.
40
Error Knife way is free, error
of the non-repeat device
(S81, S82, Y80)
- S82 does not switch off.
41
Error Knife way is not free,
error of the non-repeat device
(S81, S82, Y80)
- S81 does not switch off.
42
Error Non-repeat device, S82
was not activated
- S82 does not switch on.
43
Error Non-repeat device, S81
was not activated
- S81 does not switch on.
44
Error Non-repeat device,
none of the switches S81 or
S82 is ON
- Neither S81 nor S82 switches on.
45
Error Non-repeat device, both
of the switches S81 and S82
are ON
- S81 and S82 are switched on.
47
Error Signal for uppermost
knife position S54 is not
given
- S54 does not switch on.
48
Error cam switches, at the
start of cam side S52 (up-
wards) switch S53 (down-
wards) not ON
- S53 does not switch on.
49
Error cam switches, at the
end of cam side S53 (down-
wards) switch S52 (upwards)
not active
- S52 does not switch on.
50
Error cam switches, during
complete knife cycle none of
the cam switches S53
(downwards) or S52 (up-
wards) recognized
- S52 and S53 do not switch on.
