Perfecta 115 TS - Page 95

Service Manual 13 Errors
13.2 Error messages
1/09 PERFECTA 115 / 132 / 168 / 225 – TS 95
PERFECTA Schneidemaschinenwerk GmbH  D-02625 Bautzen  Schäfferstr. 44  Tel.: +49-3591-556-131 to -133  Fax: +49 3591-556-139
Error Message Text Remarks
51
Error cam switches, at the
end of cam side S53 (down-
wards) gape between switch
S53 and S52 (upwards)
- S52 and S53 are overlapping at the lower
dead centre.
52
Error cam switches, After
start knife-movement cam-
switches S54 (uppermost
knife position) and S53
(downwards) operate at once
- S54 and S53 are switched on at the same
time.
53
Error cam switches, cam-
switches S54 (uppermost
knife position) and S52 (up-
wards) operate at once
- S54 and S52 are switched on at the same
time.
54
Error knife over run, the knife
don't Stop uppermost knife
position (S54)
- S54 is re-enabled upon a stop.
55
Error knife movement, de-
spite activated cutting con-
tactors no knife movement
- S54 does not switch off.
56
Error knife movement, de-
spite activated cutting con-
tactors the knife don't leave
uppermost knife position
- S54 does not switch off.
57
Error cam switches, after the
end of cam side S52 (up-
wards) the uppermost knife
position (S54) was not
reached
- S54 does not switch on.
58
Error cam-switches, after the
end of cam switch down-
wards (S53), the cam switch
upwards (S52) do not switch
ON
- S52 does not switch on after S53 was
released.
65 Common light guard error - Call a service technician.
66
Error light guard, different
output signal between both
lines
- Call a service technician.
67
Error light guard, Light guard
no test signal on line 1
- Call a service technician.
68
Error light guard, Light guard
no test signal on line
- Call a service technician.
80
Error of the safety module,
no communication between
CPU 1 and CPU 2
- Call a service technician.
- Turn off the machine.
- Replace the safety module.
81
Error no communication be-
tween safety module and
control computer
- No communication between the safety
module and the control module.
82
Error of the safety module,
voltage of 24 Volt DC out of
tolerance
- Call a service technician.
- Turn off the machine.
Replace the safety module.
83
Error of the safety module,
voltage of 5 Volt DC for CPU
1 out of tolerance
- Call a service technician.
- Turn off the machine.
Replace the safety module.
