17C ENGINE TIMING
CAV fuel injection pump
Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . DPA or DPS
Direction of rotation from drive end . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Clockwise
Outlet for number 1 cylinder:
- AA, AB, AC, AD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Letter "W"
- YA, YB, YC, YD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Letter "Y"
Static timing:
The engine check angle must be used with special tool MS.67B and with the engine set with number 1
piston at top dead centre (TDC) on the compression stroke. The pump is checked with the pump set at
the start of injection for number 1 cylinder.
The code letters are included in the setting code stamped on the data plate of the fuel injection pump.
Some fuel pumps may have the setting code stamped on a modification plate which is fastened to the
flange of the pump. If a modification plate is fitted, use the code letters stamped on this plate. A typical
setting code is 2643C601BM/4/2860; in this example the code letters are "BM".
Fuel pump code
letters
Engine check
angle
(degrees)
Pump mark
angle
(degrees)
AK 325.5 336
AM 282 290.5
BM 281 291
CM 282.5 291.5
DM 282.25 290.5
FK 325.5 336
GK 324 336
GM 282 290.5
HK 327 336
HM 282 291
JK 325.5 334
KK 325 334
LK 326.5 337.5
LK(1) 329 337.5
MK 325 336
PK 326 334
RK 327.5 336
RM 282.25 290.5
TK 327 334
UK 325.5 334
XM 282 291
(1) Effective from engine list YA 31257
