Perkins Phaser Series - ASPIRATION SYSTEM

RECOMMENDED TORQUE TENSIONS 11B
Description
Thread
size
Torque
Nm lbf ft kgf m
Setscrew, idler gear hub of balancer unit M12 93 68 9,5
Nut, drive gear of balance weight 1/2 UNF 82 60 8,4
Setscrews, rear cover of balancer frame M10 54 40 5,5
Setscrews, oil transfer plate (balancer unit) M10 30 22 3,1
Setscrews, oil pump to balancer frame M8 27 20 2,8
Setscrews, balancer to cylinder block M10 54 40 5,5
Timing case and drive assembly
Setscrews, timing case to cylinder block M8 22 16 2,2
Setscrews, timing case to cylinder block M10 44 33 4,5
Setscrews, hub of idler gear M10 44 33 4,5
Setscrew, camshaft gear M12 78 58 8,0
Setscrew, camshaft gear (for engines, with 45 mm long
setscrew)
M12 100 74 10,0
Setscrews, timing case cover to timing case M8 22 16 2,2
Nuts, timing case cover to timing case M8 22 16 2,2
Cylinder block
Setscrews, fitted instead of piston cooling jets 3/8 UNF 27 20 2,8
Aspiration system
Nuts, turbocharger to manifold M10 44 33 4,5
Setscrew, breather cover M6 9 7 0,9
Fuel system
Nuts, high-pressure fuel pipes M12 22 16 2,2
Setscrews, atomiser M8 12 9 1,2
Setscrews, fuel lift pump M8 22 16 2,2
Nut for gear of fuel injection pump M14 80 59 8,2
Cap screw for gear of in-line fuel injection pump: AE, YE
engines
M8 44 33 4,5
Nut for hub of in-line fuel injection pump: AE, YE engines M18 115 84 11,8
Nuts for adaptor plate of in-line fuel injection pump: AE, YE
engines
M10 44 33 4,5
Nuts for flange of fuel injection pump M8 22 16 2,2
Locking screw for Bosch VE fuel injection pump shaft M10 27 20 2,8
Locking screw for DP 200 fuel injection pump shaft 10 A/F 10 7 1
Perkins Phaser/1000 Series, April 1995 11B.03
