Perkins Phaser Series - LUBRICATION SYSTEM

11B RECOMMENDED TORQUE TENSIONS
Description
Thread
size
Torque
Nm lbf ft kgf m
Lubrication system
Plug, lubricating oil sump 3/4 UNF 34 25 3,5
Setscrews, oil pump to front bearing cap M8 22 16 2,2
Setscrews, cover for oil pump M8 28 21 2,9
Fasteners, lubricating oil sump M8 22 16 2,2
Cooling system
Setscrews, fan drive housing to timing case M10 44 33 4,5
Setscrews, fan drive pulley to hub M8 22 16 2,2
Setscrews, fan drive pulley to hub M10 44 33 4,5
Setscrews, fan M8 22 16 2,2
Connector, oil cooler to oil filter head 3/4 UNF 58 42 5.8
Setscrews, coolant pump to timing case M8 22 16 2,2
Nut, auxiliary coolant pump pulley 1/2 UNF 70 52 7,1
Setscrew, intercooler flange to inlet manifold M6 7 5 0,7
Setscrew, intercooler body to inlet manifold M8 22 16 2,2
Flywheel and housing
Setscrews, flywheel to crankshaft 1/2 UNF 105 77 10,7
Setscrews, cast iron flywheel housing to cylinder block M10 44 33 4,5
- Stamped 8.8 M12 75 55 7,6
- Stamped 10.9 M10 63 46 6,4
- Stamped 10.9 M12 115 85 11,7
Setscrews, aluminium flywheel housing to cylinder block M10 70 52 7,1
Setscrews, flywheel housing to cylinder block (paper joint) M10 70 52 7,1
Electrical equipment
Nut, alternator pulley:
- CAV AC5RA and AC5RS 5/8 UNF 55 40 5,6
- Lucas A127, and motorola, 22mm A/F M17 60 44 6,1
- Lucas A127, and motorola, 24mm A/F M17 80 59 8,2
- Bosch 55A M14 45 33 4,5
- Bosch 55A M16 50 37 5,1
- Butec 5524 5/8 UNF 78 58 8,0
Fuelled start aid to induction manifold 7/8 UNF 31 23 3,1
Port heater aid to induction manifold M22 60 44 6,1
11B.04 Perkins Phaser/1000 Series, April 1995
