Perkins Phaser Series - Flywheel and Housing

FLYWHEEL AND FLYWHEEL HOUSING 22
Data and dimensions
Note: This information is given as a guide for personnel engaged on engine overhauls. The dimensions
which are shown are those which are mainly used in the factory. The information applies to all engines,
unless an engine type code is shown.
Flywheel and housing
Limits for flywheel housing run-out and alignment (total indicator reading)
Diameter of housing flange bore
mm in
362 14.25
Maximum limit (total indicator reading)
mm in
0,23 0.009
410 16.14 0,25 0.010
448 17.63 0,28 0.011
511 20.11 0,30 0.012
584 22.99 0,36 0.014
648 25.51 0,41 0.016
787 30.98 0,48 0.019
Perkins Phaser/1000 Series, April 1995 22A.05
