17E ENGINE TIMING
Data and dimensions
Stanadyne fuel injection pump
Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Stanadyne DB2 or DB4
Outlet for number 1 cylinder:
- 4 cylinder engines . . . . . . . . . . . . . . . . . . . . . . 8 o'clock position as seen from the rear of the pump
- 6 cylinder engines . . . . . . . . . . . . . . . . . . . . . . 9 o'clock position as seen from the rear of the pump
Direction of rotation from drive end . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Clockwise
Fuel system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Self-vent
Static timing:
The engine check angle must be used with special tool MS.67B and with the engine set with the piston of
the number 1 cylinder at top dead centre (TDC) on the compression stroke. The pump is checked with the
pump set at the start of injection for the number one cylinder.
Fuel pump
code letters
Engine check angle
(degrees)
Pump mark angle
(degrees)
AC 282 291
AL 326 336
BL 326 336
CL 327 333
DL 332 338
FL 326 333
GL 326 332
HC 282 290.5
JL 325 334.5
KM 282 290
LM 282 287
LM(1) 288.5 295
MM 282 287
MM(2) 288.5 295
NC 282 294
SL 331.5 337
SM 282 291
TM 282 290.5
VL 326 338
XK 325 331.5
YK 325 334.5
ZK 326 334
ZM 282 287.5
ZM(3) 282 289
(1) For engines fitted fuel injection pumps part numbers 2643U211 and 2643U213.
(2) For engines fitted fuel injection pump part number 2643U214.
(3) Effective from pump serial number 7665965
17E.06 Perkins Phaser/1000 Series, April 1995
