20A FUEL SYSTEM
Atomiser service settings
Code Holder Nozzle
Set and reset pressure
atm (lbf/in
2
) MPa
RD KBEL66S45 DLLA140S1039 250 3675 25,3
RE KBEL66S47 DLLA150S1055 250 3675 25,3
RF KBEL66S47 DLLA150S1072 250 3675 25,3
RH KBEL66S47 DLLA150S1087 250 3675 25,3
RK KBEL66S47 DLLA145S1172 270 3970 27,4
RM KBEL66P69 0433-175-044 250 3675 25,3
RN KBEL66P69 0433-175-067 250 3675 25,3
RP KBEL69P99 0433-175-044 250 3675 25,3
RR 0433-176-079 DSLA140P292 250 3675 25,3
RS
0433>175>079 3374287 250 3675 25,3
RT KBEL66P111 0433-175-044 250 3675 25,3
RU KBEL65P113 DSLA140P472 250 3675 25,3
The code letters are stamped on the side of the atomiser body just below the connection for the nut of the
high pressure pipe.
20A.24 Perkins Phaser/1000 Series, April 1995
