Real Time Clock 248 May 03, 2004

Philips Semiconductors Preliminary User Manual

LPC2119/2129/2194/2292/2294ARM-based Microcontroller

Table 182: Alarm Mask Register Bits (AMR - 0xE0024010)

AMR Function Description

0 AMRSEC When one, the Second value is not compared for the alarm.

1 AMRMIN When one, the Minutes value is not compared for the alarm.

2 AMRHOUR When one, the Hour value is not compared for the alarm.

3 AMRDOM When one, the Day of Month value is not compared for the alarm.

4 AMRDOW When one, the Day of Week value is not compared for the alarm.

5 AMRDOY When one, the Day of Year value is not compared for the alarm.

6 AMRMON When one, the Month value is not compared for the alarm.

7 AMRYEAR When one, the Year value is not compared for the alarm.
