Flash Memory System and Programming 273 May 03, 2004

Philips Semiconductors Preliminary User Manual

LPC2119/2129/2194/2292/2294ARM-based Microcontroller

Table 204: ISP Read Memory command description

Command R

Input

Start Address: Address from where data bytes are to be read. This address should be a word

boundary.

Number of Bytes: Number of bytes to be read. Count should be a multiple of 4.

Return Code

CMD_SUCCESS followed by <actual data (UU-encoded)> |

ADDR_ERROR (Address not on word boundary) |

ADDR_NOT_MAPPED |

COUNT_ERROR (Byte count is not multiple of 4) |

PARAM_ERROR

CODE_READ_PROTECTION_ENABLED

Description

This command is used to read data from RAM or Flash memory. As of Bootloader rev. 1.61 this

command is blocked when code read protection is enabled.

Example "R 1073741824 4<CR><LF>" reads 4 bytes of data from address 0x4000 0000.
