Install the Seeger ring.
•
Install the roller bearing using the spe-
cial tool.
Specific tooling
020083Y Punch
•
Heat the connections on the engine
crankcase and insert the bearings to
abutment using the modular punch.
•
To install the right bearing, lower the
engine.
N.B.
WHEN HEATING THE LEFT SEAT MOVE THE HOSE FOR
OIL TO THE BRAKE CLAMP AWAY FROM THE ENGINE
CRANKCASE. FOR THE RIGHT PART REMOVE AND
MOVE AWAY THE BRACKET SUPPORTING THE WIRING.
Specific tooling
020151Y Air heater
020359Y 42x47-mm Adaptor
020363Y 20-mm guide
020376Y Adaptor handle
Beverly 500 i.e. Suspensions
SUSP - 279
