Specification Desc./Quantity
31 Lhs turn signal warning light
32 Instrument lighting
33 Headlamp warning light
34 Front turn signal light bulb 12V-10W
35 Intercom fitting
36 Engine stop switch
37 Fitting for accessories
38 Front wire node (black)
39 Indicators remote control switch
40 Electric fan solenoid
41 Light switch
42 Starter button
43 Damper for fuel level indicator
44 Key switch
45 Immobilizer aerial
46 Decoder
47 Front ground node
48 Injection ECU
49 Intercom pre-wiring
50 Fuel injector
51 Throttle potentiometer
52 Idle adjustment motor
53 Air temperature sensor
54 Engine Speed sensor
55 Shielded bi-polar cable
56 Engine water temperature sensor
57 Engine oil pressure sensor
58 Flywheel magneto
59 Frame ground
60 Ground cable
61 Starter motor wire
62 Starter motor
63 Start-up solenoid
64 Battery 12V-12Ah
65 Rear fuse box
66 Fuse 30A
67 Fuse 15A
68 Two 10A fuses
69 Fuse 5A
70 Fuse 3A
71 L.V. socket (12V - 180W)
72 12V D.C. regulator
73 Wire node (red-black)
74 Engine stop remote control switch
75 Two 30A relays
76 Control unit remote control switch
77 ECU diagnostic socket
78 Wire node (red-yellow)
79 Wire node (yellow-black)
80 Helmet compartment light button
81 Rear wire node (black)
Colours of the electrical cables:
B = White, Bl = Blue, G = Yellow, Mr = Brown, N = Black, Gr = Grey,
Rs = Pink, R = Red, Vi = Purple, V = Green
CAUTION
SHOULD ANY INTERVENTIONS TO THE ELECTRIC SYSTEM BE REQUIRED, MAKE SURE THAT
THE LEADS TO THE ELECTRONIC IGNITION DEVICE ARE PROPERLY CONNECTED ACCORD-
ING TO POLARITY AND TO THE LEAD COLOURS.
Electrical system Beverly 500 i.e.
ELE SYS - 34
