7 General
Installation manual for PMC tendo DD5/PMCprimo Drive3 Page 19
7.7 Technical data
7.7.1 Technical data 230 V series
Rated data
DIM
PMCtendo DD5
PMCprimo Drive3
Size — 3A 6A 10A
Rated supply voltage(grounded supply, phase to
phase)
V~ 1 x 110V
-10%
… 1 x 230V
+10%
3 x 110V
-10%
… 3 x 230V
+10%
50/60 Hz
Rated input power for S1 operation kVA 1.1 2.4 4
Max. DC bus link voltage V= 450
Rated output current (rms value, ± 3%)
at 1x110V Arms 3 3 3
at 3x115V Arms 3.5 8 10
at 3x230V Arms 3 6 10
at 1x230/240V Arms 3 4 4
Peak output current (rated current x 2 for approx. 5s, ± 3%)
at 1x110V Arms 5 5 5
at 3x115V Arms 9 15 20
at 3x230V Arms 9 15 20
at 1x230/240V Arms 9 9 9
Switching frequency of the output stage kHz 8 (16*)
Technical data for regen circuit —  p. 26
Threshold for overvoltage switch-off VDC 235 / 455
Motor inductance min.
at 1x110V mH 3.7 3.7 3.7
at 3x115V mH 2.1 1.3 1.0
at 3x230V mH 4.3 2.6 1.9
at 1x230/240V mH 4.3 4.3 4.3
Motor inductance max. mH Consult our customer support
Form factor of the output current(rated
conditions, min. load inductance)
—
1.01
Bandwidth of current controller kHz > 1,2
Residual voltage drop at rated current V 4
Thermal dissipation, output stage disabled W 12
Thermal dissipation at rated current (incl. PSU
losses, without regen dissipation)
W 35 60 90
Mechanical
Weight kg ca. 2.6
Height, without connectors mm 275 278
Width mm 70
Depth, without connectors mm 171
Depth, with connectors mm < 200
* at reduced current
