10 Setup
Page 94 Installation manual for PMCtendo DD5/PMCprimo Drive3
10.4.2 Keypad operation PMCtendo DD5
This section illustrates the two possible operating menus and the use of the keys on the front
panel. Normally, the only presents the standard menu for your use. If you want to operate the
amplifier via the detailed menu, you must keep the right key pressed while switching on the 24V
supply.
10.4.2.1 Keypad operation
The two keys can be used to perform the following functions:
Key symbol functions
press once : move up one menu item, increase number by one
press twice in rapid succession : increase number by ten
press once : move down one menu item, decrease number by one
press twice in rapid succession : decrease number by ten
hold right key pressed, and then press left key as well :
to enter a number, “Return” function
10.4.2.2 Status display
