10 Setup
Installation manual for PMC tendo DD5/PMCprimo Drive3 Page 99
10.7 Warning messages PMCtendo DD5
Faults which occur, but which do not cause a switch-off of the amplifier output stage (BTB/RTO
contact remains closed), are indicated in the LED display on the front panel by a coded warning
number. Detailled description see "ASCII command reference”
Number Designation Explanation
E/S/A/P
status Messages status messages, no error, see p. 94
. . .
status Message amplifier is updating the startup configuration
-
status Message status message, no error, programming mode
n01
I²t I²t threshold exceeded
n02
regen power reached preset regen power limit
n03*
S_fault exceeded preset following error limit
n04*
response monitoring response monitoring (fieldbus) has been activated
n05
supply phase mains supply phase missing
n06*
SW limit switch 1 passed software limit switch 1
n07*
SW limit switch 2 passed software limit switch 2
n08
motion task error a faulty motion task was started
n09
no reference point no reference point (Home) set at start of motion task
n10*
PSTOP PSTOP limit-switch activated
n11*
NSTOP NSTOP limit-switch activated
n12
motor default values
loaded
only for ENDAT or HIPERFACE® :discrepancy between
motor number saved in the encoder and the amplifier,
motor default values loaded
n13*
expansion card expansion card not operating correctly
n14
SinCos feedback SinCos commutation (wake & shake) not completed, will
be canceled when amplifier is enabled and wake & shake
carried out
n15
table error fault according to speed/current table INXMODE 35
n16
summarized warning summarized warning for n17 to n31
n17
fieldbus-sync sync is not logged in
n18
multiturn overflow max. number of motor turns exceeded
n19-n31
reserve reserve
n32
firmware beta version firmware is an unreleased beta version
A
reset RESET is present on input DIGITAL INx
* = these warning messages result in a controlled shut-down of the drive (braking by emergency
stop ramp)
You can find further information on handling errors from page 113 and in the "ASCII
command reference" (part of the setup software's online help system)
