7 General
Page 26 Installation manual for PMCtendo DD5/PMCprimo Drive3
7.10.2 Technical Data
Regen circuit
Supply voltage
Rated data DIM 115 V 230 V 400 V 480 V
Switch-on (upper) threshold of regen circuit V 200 400
Overvoltage F02 V 235 455
Regen resistor (internal) Ohm 66 66
Continuous power in regen circuit (RBint) W 20 20
Pulse power in regen circuit (RBint max. 1s) kW 0.75 3
Regen resistor (external)* Ohm 66 66
Continuous power in regen circuit (RBext) max. kW 0.3 0.3
230V series
3A
Pulse power in regen circuit (RBext max. 1s) kW 0.75 3
—
Switch-on (upper) threshold of regen circuit V 200 400
Overvoltage F02 V 235 455
Regen resistor (internal) Ohm 66 66
Continuous power in regen circuit (RBint) W 50 50
Pulse power in regen circuit (RBint max. 1s) kW 0.75 3
Regen resistor (external)* Ohm 66 66
Continuous power in regen circuit (RBext) max. kW 1 1
230V series
6A and 10A
Pulse power in regen circuit (RBext max. 1s) kW 0.75 3
—
Switch-on (upper) threshold of regen circuit V 400 720 840
Overvoltage F02 V 455 800 900
Regen resistor (internal) Ohm 91 91 91
Continuous power in regen circuit (RBint) W 20 20 20
Pulse power in regen circuit (RBint max. 1s) kW 2.1 7 9
Regen resistor (external)* Ohm 91 91 91
Continuous power in regen circuit (RBext) max. kW 0.3 0.3 0.3
480V series
1.5A
Pulse power in regen circuit (RBext max. 1s) kW
—
2.1 7 9
Switch-on (upper) threshold of regen circuit V 400 720 840
Overvoltage F02 V 455 800 900
Regen resistor (internal) Ohm 91 91 91
Continuous power in regen circuit (RBint) W 50 50 50
Pulse power in regen circuit (RBint max. 1s) kW 2.1 7 9
Regen resistor (external)* Ohm 91 91 91
Continuous power in regen circuit (RBext) max. kW 1.0 1.0 1.0
480V series
3A and 6A
Pulse power in regen circuit (RBext max. 1s) kW
—
2.1 7 9
* Partially other resistance values are possible. Please ask our customer support.
