8.4.5.2 Technical data for connecting cables
Further information on the chemical, mechanical and electrical characteristics of the cables can
be obtained from our customer service.
Observe the rules in the section "Conductor cross-sections" on page 22. To reach the
max. permitted cable length, you must use cable material that matches the capacitance
requirements listed below.
8.4.5.3 Insulation material
Sheating PUR (polyurethane, code 11Y)
Core insulation PETP (polyesteraphtalate, code 12Y)
8.4.5.4 Capacitance
Motor cable less than 150 pF/m
Resolver-/Encoder cable less than 120 pF/m
8.4.5.5 Technical data
• The brackets in the core definition indicate the shielding.
• All cables are suitable for use as trailing cables.
• The technical data refer to use as moveable cables.
• Operating life : 1 million bending cycles
Cores
[mm²]
max.
length
[m]
Use for Operating-
temp. range
[°C]
Outside
diameter
[mm]
Bending
radius
[mm]
(4x1.0) 50* motor
power
-30 / +80 10 100
(4x1.5) 50* motor
power
-30 / +80 10.5 105
(4x1.0+(2x0.75)) 50* motor incl.
brake
-30 / +80 10.5 105
(4x1.5+(2x0.75)) 50* motor incl.
brake
-30 / +80 11.5 120
(4x(2x0.25)) 100* Resolver -30 / +80 7.7 70
(7x(2x0.25)) 50* Encoder -30 / +80 9.9 90
* North America supplies cables up to 39 meters
* Europe supplies cables up to max. length
Motor cables longer than 25m only with motor choke.
You can order a special motor choke from us.
