Display menu - Configuration
Operating Manual PNOZ s30
1001715-EN-19
| 74
Level Designation
on the display
Description Settings
3 Track Z Tol.
Default:
Off
Enter tolerance time for invalid
signal level on track Z.
This tolerance time is only ef-
fective on encoder types "rotary
encoder + pnp proximity
switch".
} Off
} 50 ms … 2500 ms
2 Track S Settings for track S (error track)
3 Track S
Default:
Not used
Use of track S:
-Not used (track S is not used)
-Evaluation (track S is used)
} Not used
} Evaluation
3 Track S Umax
Default:
6.0 V
Enter max. voltage at track S.
If the voltage is > Umax, an er-
ror is displayed and the outputs
are switched off.
0.0 V ... 30.0 V
3 Track S Umin
Default:
2.0 V
Enter min. voltage at track S.
If the voltage is < Umin, an error
is displayed and the outputs are
switched off.
0.0 V ... 30.0 V
3 Track S Tol.
Default:
Off
Enter tolerance time for invalid
signal level on track S.
} Off
} 50 ms … 2500 ms
1 Delay Time
Startup
Default:
0.00 s
Select start-up delay
(The start-up phase of the
PNOZ s30 is extended by this
time. The encoder signals are
not evaluated until after the
start-up phase.)
0 ... 600 s
1 Function Para-
meter
Select function parameter
