Display menu - Configuration
Operating Manual PNOZ s30
1001715-EN-19
| 75
Level Designation
on the display
Description Settings
2 Standstill
vmax:
Default:
2.00Hz
Select standstill frequency
Validation cut-off frequency:
As implausible signals may
arise due to edge jitter on the
encoders around the standstill
position, a validation cut-off fre-
quency must be configured for
"proximity switch" encoder
types (without rotary encoder)
(edge jitter is caused by the po-
sition control of the drive fre-
quency converter or by external
interference signals).
If the value of the validation cut-
off frequency falls below the
configured value, the plausibility
check of the sensors will no
longer be run.
10 mHz ... 1.00MHz
or the corresponding value in the selected
unit
2 (F1 ... F9)
Parameter
Enter parameter for the switch
functions F1 ... F9
3 (F1 ... F9)
(P0 ... P15)
Parameter
Default:
10mHz
For each switch function F1 ...
F9 up to 16 parameters P0 ...
P15 can each be configured.
4 (F1 ... F9)
(P0 ... P15)
Teach v max:
Display:
Current linear/rota-
tional speed
The current linear/rotational
speed is displayed and can be
adopted as a limit value.
4 (F1 ... F9)
(P0 ... P15)
vmax:
Standstill
"Standstill" is displayed and
can be adopted
Info:
The standstill frequency is se-
lected globally in the menu
"Standstill vmax: "
(see above)
