Display menu - Configuration
Operating Manual PNOZ s30
1001715-EN-19
| 76
Level Designation
on the display
Description Settings
4 (F1 ... F9)
(P0 ... P15)
vmax:
2.00kHz
Select linear/rotational speed
limit
10 mHz ... 1.00MHz
or the corresponding value in the selected
unit
4 (F1 ... F9)
(P0 ... P15)
Function
Position(1 … 4)
Select position monitoring 1 ... 4
4 (F1 ... F9)
(P0 ... P15)
Function
(Direct. Left, Dir-
ect. Right)
Select left-hand or right-hand
direction monitoring
4 (F1 ... F9)
(P0 ... P15)
Fixed value
(On/Off)
Select static value On or Off
2 Special Functions A special function can be con-
figured for each parameter set
(except in select mode "None")
3 (P0 ... P15)
Default:
none
A special function can be con-
figured for each parameter set
(except in select mode "None")
The special functions are activ-
ated via the select inputs.
} none
} No2-Enc-Diag.
With this setting, please also refer to the
guidelines stated under 2 encoder dia-
gnostics / broken shearpin
monitoring [ 21]
} ErrorAcknowledge
} Restart
1 Assign Outputs Assign functions to outputs
