Planet IGS-10020 Series User Manual

User’s Manual
239
 MAC Parameters
Object Description
• SMAC Filter
(Only displayed when the frame type is Ethernet Type or ARP.)
Specify the source MAC filter for this ACE.
■ Any: No SMAC filter is specified. (SMAC filter status is "don't-care".)
■ Specific: If you want to filter a specific source MAC address with this ACE,
choose this value. A field for entering an SMAC value appears.
• SMAC Value
When "Specific" is selected for the SMAC filter, you can enter a specific source MAC
address. The legal format is "xx-xx-xx-xx-xx-xx" or "xx.xx.xx.xx.xx.xx" or
"xxxxxxxxxxxx" (x is a hexadecimal digit). A frame that hits this ACE matches this
SMAC value.
• DMAC Filter
Specify the destination MAC filter for this ACE.
■ Any: No DMAC filter is specified. (DMAC filter status is "don't-care".)
■ MC: Frame must be multicast.
■ BC: Frame must be broadcast.
■ UC: Frame must be unicast.
■ Specific: If you want to filter a specific destination MAC address with this
ACE, choose this value. A field for entering a DMAC value appears.
• DMAC Value
When "Specific" is selected for the DMAC filter, you can enter a specific destination
MAC address. The legal format is "xx-xx-xx-xx-xx-xx" or "xx.xx.xx.xx.xx.xx" or
"xxxxxxxxxxxx" (x is a hexadecimal digit). A frame that hits this ACE matches this
DMAC value.
 VLAN Parameters
Object Description
• 802.1Q Tagged
Specify whether frames can hit the action according to the 802.1Q tagged. The allowed
values are:
 Any: Any value is allowed ("don't-care").
 Enabled: Tagged frame only.
 Disabled: Untagged frame only.
The default value is "Any".
• VLAN ID Filter
Specify the VLAN ID filter for this ACE.
■ Any: No VLAN ID filter is specified. (VLAN ID filter status is "don't-care".)
■ Specific: If you want to filter a specific VLAN ID with this ACE, choose this
value. A field for entering a VLAN ID number appears.
• VLAN ID
When "Specific" is selected for the VLAN ID filter, you can enter a specific VLAN ID
number. The allowed range is 1 to 4095. A frame that hits this ACE matches this VLAN
ID value.
