• Tag Priority
Specify the tag priority for this ACE. A frame that hits this ACE matches this tag priority.
The allowed number range is 0 to 7. The value Any means that no tag priority is
specified (tag priority is "don't-care".)
 ARP Parameters
The ARP parameters can be configured when Frame Type "ARP" is selected.
Object Description
• ARP/RARP
Specify the available ARP/RARP opcode (OP) flag for this ACE.
■ Any: No ARP/RARP OP flag is specified. (OP is "don't-care".)
■ ARP: Frame must have ARP/RARP opcode set to ARP.
■ RARP: Frame must have ARP/RARP opcode set to RARP.
■ Other: Frame has unknown ARP/RARP Opcode flag.
• Request/Reply
Specify the available ARP/RARP opcode (OP) flag for this ACE.
■ Any: No ARP/RARP OP flag is specified. (OP is "don't-care".)
■ Request: Frame must have ARP Request or RARP Request OP flag set.
■ Reply: Frame must have ARP Reply or RARP Reply OP flag.
• Sender IP Filter
Specify the sender IP filter for this ACE.
■ Any: No sender IP filter is specified. (Sender IP filter is "don't-care".)
■ Host: Sender IP filter is set to Host. Specify the sender IP address in the
SIP Address field that appears.
■ Network: Sender IP filter is set to Network. Specify the sender IP address
and sender IP mask in the SIP Address and SIP Mask fields that appear.
• Sender IP Address
When "Host" or "Network" is selected for the sender IP filter, you can enter a
specific sender IP address in dotted decimal notation.
• Sender IP Mask
When "Network" is selected for the sender IP filter, you can enter a specific
sender IP mask in dotted decimal notation.
• Target IP Filter
Specify the target IP filter for this specific ACE.
■ Any: No target IP filter is specified. (Target IP filter is "don't-care".)
■ Host: Target IP filter is set to Host. Specify the target IP address in the
Target IP Address field that appears.
■ Network: Target IP filter is set to Network. Specify the target IP address
and target IP mask in the Target IP Address and Target IP Mask fields that
appear.
• Target IP Address
When "Host" or "Network" is selected for the target IP filter, you can enter a
specific target IP address in dotted decimal notation.
• Target IP Mask
When "Network" is selected for the target IP filter, you can enter a specific target
IP mask in dotted decimal notation.
