Planet IGS-10020 Series User Manual

User’s Manual
43
IGS-10080MFT
 System
LED Color Function
P1 Green Indicates power 1 has power.
P2 Green Indicates power 2 has power.
Fault Green Indicates either power 1 or power 2 has no power.
Ring
On Indicates the ERPS Ring has been created successfully.
Off Indicates the ERPS Ring hasn’t been created.
R.O.
Green Indicates the Ring Owner has been enabled.
Off Indicates the Ring Owner hasn’t been enabled.
 Per 10/100/1000BASE-T Port
LED Color Function
LNK/ACT Green
Lights
Indicates the link through that port is successfully established.
Blinks
Indicates that the Switch is actively sending or receiving data over that
port.
1000 Orange
Lights
Indicates that the port is successfully connecting to the network at
1000Mbps.
Off
Indicates that the port is successfully connecting to the network at 10 /
100Mbps.
 Per SFP Interface
LED Color Function
1000
LNK/ACT
Green
Lights
Indicates the link through that port is successfully established.
Blinks
Indicates that the Switch is actively sending or receiving data over that
port.
100
LNK/ACT
Orange
Lights
Indicates that the port is successfully connecting to the network at
100Mbps.
Blinks
Indicates that the Switch is actively sending or receiving data over that
port.
