ENGINE
2.25
Disassembly, Cont.
9. Remove recoil housing and drive hub.
10. Remove flywheel using heavy-duty flywheel puller.
Use drive clutch puller T-handle or a wrench to hold
puller.
11. Before removing stator plate, note where ignition
timing marks are located, or scribe additional marks
for reference upon reassembly.
12. Mark or note location of engine mount straps and
remove.
Flywheel Puller PN 2871043
T-Handle PN 5020326
